USB-8486
Modular Systems > National Instruments > Serial Interface Devices
| Description: | USB-8486, 1-Port, Fieldbus Interface Device |
Need an Official Quote?
Or speak to a sales representative for additional information:
Phone:1-800-915-6216
Email:sales@apexwaves.com
National Instruments USB-8486 Fieldbus Interface Device
The USB-8486 is a Fieldbus Interface Device. The NI USB-8486 Fieldbus Interface Device is made by National Instruments. The USB-8486 is available for purchase with NI part numbers 781160-01 and 781160-02. These variants have the same technical performance parameters, but only vary in the options of screw retention and mounting options. The NI USB-8486 device supports the FOUNDATION Fieldbus. In industrial control applications, the FOUNDATION Fieldbus is a widely acclaimed standard for signal communication.
The USB-8486 Fieldbus Interface Device comes with NI-FBUS Communication Manager software, which is compatible with the Windows OS. The compatible software programs for the NI USB-8486 device are the NI-FBUS Configurator, NI-FBUS Monitor, and LABVIEW graphical programming. The NI-FBUS Configurator serves the purpose of configuration and setting for FOUNDATION Fieldbus through dynamic user-interface tools. The monitoring, debugging, troubleshooting, and analysis of FOUNDATION Fieldbus data is carried out by the NI-FBUS Monitor application.
The National Instruments USB-8486 Fieldbus Interface Device is a plug-and-play device that is available with a single port supporting USB 2.0 connectivity. The maximum baud rate of the USB-8486 device is 31.25 kb/s. The NI USB-8486 features a standard H1 interface for Fieldbus which is provided with a 9-pin male D-SUB connector. The USB-8486 Fieldbus Interface Device requires up to 300 mA current in working mode, while only 2.5 mA current is drawn in suspended mode. The NI USB-8486 device is designed for indoor applications only. The performance parameters are ideal when the device is operated within the ambient temperature range of 0 to 55o C.
| Model | USB-8486 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 781160-02 and 781160-01 |
| Type | Fieldbus Interface Device |
| Ports | 1 |
| Bus Connector | USB 2.0 |
| FOUNDATION™ Fieldbus H1 Interface | 9-pin male D-SUB |
| Working Mode Current | 300 mA maximum (full temperature range); 180 mA typical (at 25°C) |
| Dimensions | Screw Retention: 3.39 × 2.5 × 1.18 in. Without Screw Retention: 3.1 × 2.5 × 1.0 in. |
| Weight | Screw Retention: 6.17 oz. Without Screw Retention: 5.82 oz. |
| Warranty | 2-3 Year Warranty |
| USB-8486 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for USB-8486:
190759A-01L, 190759A-02L, 190759B-01L, 190759B-02L, 190759C-01L, 190759C-02L, 190759D-01L, 190759D-02L, 781160-01, 781160-02
USB-8486 PDF Manuals
ARCHIVED FOUNDATION FIELDBUS OVERVIEW.PDF
FOUNDATION FIELDBUS HARDWARE AND NI FBUS SOFTWARE FOR WINDOWS INSTALLATION GUIDE.PDF
FOUNDATION FIELDBUS HARDWARE AND NI FBUS SOFTWARE INSTALLATION GUIDE.PDF
FOUNDATION FIELDBUS OVERVIEW.PDF
NI FBUS CONFIGURATOR USER MANUAL.PDF
NI FBUS HARDWARE AND SOFTWARE USER MANUAL AND SPECIFICATIONS.PDF
NI FBUS HARDWARE AND SOFTWARE USER MANUAL.PDF
NI FBUS MONITOR USER MANUAL.PDF
USB-8486 FOUNDATION FIELDBUS NOTE TO USERS.PDF
USB-8486 LETTER OF VOLATILITY.PDF
Why Buy From Apex Waves:
"The business transaction was super easy and friendly."
"Hand carrying parts to fedex directly to make sure I get them overnight. Great service"
"They were very helpful to get me the test equipment that I need."
USB-8486
Modular Systems > National Instruments > Serial Interface Devices
USB-8486, 1-Port, Fieldbus Interface Device
1-800-915-6216
- Description
- Technical Specifications
- Manuals & PDFs
National Instruments USB-8486 Fieldbus Interface Device
The USB-8486 is a Fieldbus Interface Device. The NI USB-8486 Fieldbus Interface Device is made by National Instruments. The USB-8486 is available for purchase with NI part numbers 781160-01 and 781160-02. These variants have the same technical performance parameters, but only vary in the options of screw retention and mounting options. The NI USB-8486 device supports the FOUNDATION Fieldbus. In industrial control applications, the FOUNDATION Fieldbus is a widely acclaimed standard for signal communication.
The USB-8486 Fieldbus Interface Device comes with NI-FBUS Communication Manager software, which is compatible with the Windows OS. The compatible software programs for the NI USB-8486 device are the NI-FBUS Configurator, NI-FBUS Monitor, and LABVIEW graphical programming. The NI-FBUS Configurator serves the purpose of configuration and setting for FOUNDATION Fieldbus through dynamic user-interface tools. The monitoring, debugging, troubleshooting, and analysis of FOUNDATION Fieldbus data is carried out by the NI-FBUS Monitor application.
The National Instruments USB-8486 Fieldbus Interface Device is a plug-and-play device that is available with a single port supporting USB 2.0 connectivity. The maximum baud rate of the USB-8486 device is 31.25 kb/s. The NI USB-8486 features a standard H1 interface for Fieldbus which is provided with a 9-pin male D-SUB connector. The USB-8486 Fieldbus Interface Device requires up to 300 mA current in working mode, while only 2.5 mA current is drawn in suspended mode. The NI USB-8486 device is designed for indoor applications only. The performance parameters are ideal when the device is operated within the ambient temperature range of 0 to 55o C.
| Model | USB-8486 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 781160-02 and 781160-01 |
| Type | Fieldbus Interface Device |
| Ports | 1 |
| Bus Connector | USB 2.0 |
| FOUNDATION™ Fieldbus H1 Interface | 9-pin male D-SUB |
| Working Mode Current | 300 mA maximum (full temperature range); 180 mA typical (at 25°C) |
| Dimensions | Screw Retention: 3.39 × 2.5 × 1.18 in. Without Screw Retention: 3.1 × 2.5 × 1.0 in. |
| Weight | Screw Retention: 6.17 oz. Without Screw Retention: 5.82 oz. |
| Warranty | 2-3 Year Warranty |
| USB-8486 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
