National Instruments 780103-01 USB Multifunction I/O Device
The National Instruments 780103-01, also known as the USB-6210, is a bus-powered M Series data acquisition device designed for measuring and controlling signals from a wide range of sensors and equipment. It combines analog inputs, digital I/O, and timing functions in a compact unit, making it suitable for applications where space, portability, and power consumption are important considerations.
The 780103-01 provides 16 single-ended or 8 differential analog input channels with 16-bit resolution and an aggregate sampling rate of up to 250 kS/s. Four selectable input ranges—±200 mV, ±1 V, ±5 V, and ±10 V—allow the device to accommodate different signal levels. It also includes four digital inputs and four digital outputs with TTL compatibility, along with two 32-bit counters for applications such as encoder tracking, event counting, frequency measurement, and pulse-width modulation (PWM).
A built-in amplifier helps the device settle quickly when scanning multiple channels, supporting accurate measurements during high-speed and dynamic testing. The USB Multifunction I/O Device uses USB 2.0 for both communication and power, eliminating the need for a separate power supply. This bus-powered design makes the device particularly convenient for portable test equipment, mobile data acquisition systems, and applications in locations where access to external power may be limited.
The device supports bidirectional data transfer over USB, allowing it to handle sustained measurement operations while communicating with a host computer. Screw-terminal connections provide a convenient way to connect sensors, actuators, and other external signals directly to the unit.
The USB-6210 supports analog and digital triggering, giving users control over when measurements or other operations begin. Its digital I/O and counter functions also make it useful for control applications, frequency measurement, encoder monitoring, and PWM generation.
The 780103-01 is well suited to portable data loggers, mobile measurement systems, laboratory equipment, industrial testing, and OEM designs where a compact and power-efficient data acquisition solution is required. It can be integrated into test benches or portable equipment and is supported by NI-DAQmx software and configuration tools for setting up and operating data acquisition systems.
With its combination of flexible analog inputs, digital I/O, counter functions, USB connectivity, and bus-powered operation, the USB-6210 provides a practical solution for engineers and researchers who need reliable measurement and control capabilities in a compact form.
| Model | 780103-01 |
|---|---|
| Part Number | 780103-01 |
| Part Type | M Series Bus-Powered DAQ |
| Analog Inputs | 16 SE / 8 DIFF channels |
| ADC Resolution | 16-bit |
| Max Sample Rate | 250 kS/s aggregate |
| Voltage Ranges | ±200 mV, ±1 V, ±5 V, ±10 V |
| Digital I/O | 4 inputs, 4 outputs (TTL) |
| USB Interface | 2.0, self-powered via bus |
| Connectivity | Screw-terminal block |
