National Instruments 780117-04 USB Multifunction I/O Device
The National Instruments 780117-04, also known as the USB-6221, is an M Series multifunction data acquisition device that connects to a computer through USB and features BNC connections for reliable signal connections. This model is configured for 240 V European power standards and includes NI-DAQmx software and configuration tools to simplify device setup, measurement configuration, and data collection.
The 780117-04 provides 16 analog input channels with 16-bit resolution and an aggregate sampling rate of up to 250 kS/s. It also includes two analog output channels, 24 correlated digital I/O lines, two 32-bit counters/timers, and digital triggering capabilities. The BNC connections allow signals to be connected directly using coaxial cables, making the device particularly well suited to laboratory and test environments where secure connections and good signal integrity are important.
The device supports a wide range of applications, including laboratory automation, research and development, design verification, manufacturing testing, and production testing. Its correlated digital I/O allows analog and digital operations to be synchronized, which is useful for automated test systems, monitoring, and closed-loop control applications.
The 780117-04 supports input voltage levels from ±200 mV to ±10 V, allowing it to work with a variety of sensors and signal sources. For applications requiring additional signal conditioning, the device can be paired with compatible SCC or SCXI modules. These modules can expand the system's capabilities to accommodate sensors such as thermocouples, strain gauges, and accelerometers, as well as higher-voltage inputs.
NI-DAQmx software provides a consistent way to configure channels, set measurement timing, and manage data collection. It also supports development across a range of compatible programming environments, helping simplify the process of integrating the device into custom measurement and automated test systems.
The USB connection provides convenient plug-and-play installation and makes the USB Multifunction I/O Device easy to deploy in both benchtop and test-station environments. By combining analog and digital I/O, counter/timer functions, flexible signal ranges, and expandable signal-conditioning options in one compact device, the 780117-04 offers a practical and versatile solution for measurement, monitoring, and automated testing applications.
| Model | 780117-04 |
|---|---|
| Part Number | 780117-04 |
| Part Type | M Series Multifunction USB DAQ Device |
| Operating Voltage | 240V Euro |
| Analog Input Channels | 16 single-ended / 8 differential |
| Analog Output Channels | 2 voltage output channels |
| ADC Resolution | 16-bit |
| Sampling Rate | 250 kS/s aggregate |
| Digital I/O Lines | 24 correlated lines |
| Counter/Timers | 2 × 32-bit |
