VXI-1500
Modular Systems > National Instruments > VXI and VME
| Description: | VXI-1500, 13-slot, C-size, VXI Mainframe |
Need an Official Quote?
Or speak to a sales representative for additional information:
Phone:1-800-915-6216
Email:sales@apexwaves.com
National Instruments VXI-1500 VXI Mainframe
The VXI-1500 is a VXI Mainframe produced by National Instruments. The NI VXI-1500 contains a backplane with 13 slots and a high-output power supply. The VXI-1500 is made with a structural design that renders optimization tools for maximum use in multiple applications. The VXI-1500 Mainframe is compatible with the VXIbus Specification Revision 1.4.
This VXI Mainframe has a low mean time to repair (MTTR), since it has a high level of maintainability. The NI VXI-1500 is built with 13 C-sized VXIbus slots. The VXIbus slots can also fit A-sized and B-sized modules if adapters are used. The NI VXI-1500 is designed without backplane jumpers. The VXI-1500 uses 1100 W of heat dissipation through filtered forced-air cooling. This VXI Mainframe has 1100 W (115 VAC input) or 1420 W (230 VAC input) power.
The NI VXI-1500 is manufactured with universal AC input, which means the mainframe can utilize auto-voltage as well as auto-frequency ranging. The NI VXI-1500 has overcurrent protection through push-reset circuit breakers. The VXI-1500 is equipped with a removable power supply with a MTBF of 50,000 hours. There is a remote power monitoring and inhibit through a back-panel connector as well. An On/Off switch on the front panel allows for simple access and is recessed to stop accidental switching. This VXI Mainframe has two configuration options; it can be rackmounted or installed on a bench.
VXI-1500 Obsolete Status has been announced by National Instruments, but the mainframe will still be available for purchase and repairs by Apex Waves.
| Model | VXI-1500 |
|---|---|
| Manufacturer | National Instruments |
| Type | VXI Mainframe |
| Slots | 13 |
| Size | C-size |
| Per Slot Cooling Capacity | 85 W |
| Input Voltage Range | 85 to 264 VAC |
| Input Frequency Range | 47 to 500 Hz |
| Over-Current Protection | 15 A circuit breaker |
| Dimensions | 15.45 in. x 17.20 in. x 28.02 in. |
| Weight | 62 lb. (without modules) |
| Warranty | 2-3 Year Warranty |
| VXI-1500 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the VXI-1500:
184146A-01, 777423-01, 777423-02, 777423-03, 777423-04, 777423-05, 777423-06, 777424-01
