VXI-1501

4.9/5 | 5 ratings

Modular Systems > National Instruments > VXI and VME

Part Number VXI-1501
Manufacturer/Brand National Instruments
Description: VXI-1501, 13-slot, VXI Mainframe
Request for Availablility
Fast Quote
Quoted Price
Same Day Calibration Available
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing

Need an Official Quote?



Or speak to a sales representative for additional information:


National Instruments VXI-1501 Mainframe

The VXI-1501 Mainframe is developed and designed by National Instruments. The VXI-1501 mainframe has 13 slots for different types of modules. The Mainframe has a reversible base, which can be mounted on each position on the rack. This Mainframe is fully compatible with the VXI family. The NI VXI-1501 Mainframe has a reliable power supply, which can be operated on any standard line voltages, i.e. 110 VAC or 220VAC. The National Instruments VXI-1501 can be operated from a 400 Hz frequency AC line or DC line.

Variable speed fans are installed in the mainframe to cool down the power supply module, as well as the mainframe modules. Two types of fan modes are helpful for meeting the cooling requirements of the mainframe. The VXI-1501 has seven types of supply voltages, which are all electrically protected, such as overvoltage, overcurrent, and thermally protected.

The maximum power utilized by the NI VXI-1501 Mainframe is 1690 W at 25° C and 1488 W at 55° C. The Mainframe can supply sufficient air flow to the 13 slots to cool down 60 W across the dense module, maintaining 10° C rise at the most. VXI facilitates easy maintenance by providing easily removable parts for replacing without dismantling from the rack. A 25-pin port is installed at the rear side of the mainframe to facilitate the monitoring of the auxiliary power supply.

VXI-1501 Obsolete Status has been announced by National Instruments, but the mainframe will still be available for purchase and repairs by Apex Waves.

ModelVXI-1501
ManufacturerNational Instruments
TypeVXI Mainframe
Slots13
SizeC-size
Input Voltage Range100 VDC min; 370 VDC max
50–60 Hz Input PowerAutomatic voltage ranging
Inrush Current40 A max
Weight48.5 lbs. (without modules)
Warranty2-3 Year Warranty
VXI-1501 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for the VXI-1501:

745740-01, 778125-01
