USB-6353, 32 AI, 4 AO, 48 DIO, 4 Counters/Timers, USB Multifunction I/O Device
Need an Official Quote?
National Instruments USB-6353 Multifunction I/O Device
The NI USB-6353 (Part Number: 781441-01) includes 32 analog input channels. These 32 single-ended channels can also be operated as 16 differential channels. This device offers an impressive sample rate through its input channels. 1.25 MS/s is the greatest sample rate for a single channel. 1.00 MS/s is the greatest sample rate for multiple channels. The timing resolution of the input channels is 10 ns. The USB-6353 NI also offers a timing accuracy of 50 ppm.
The USB-6353 has one analog trigger, which can be utilized for different triggering functions. The source level of the trigger for AI<0.31> is ±Full scale. The source level of the trigger for APFI<0.1> is ±10 Volts. The analog trigger offers measurements of 16-bits resolution. This trigger works in different modes. The most common mode is analog edge triggering. The analog trigger provides an input resistance of 10 kΩ. This Multifunction I/O Device has different protection values for the ‘on’ and ‘off’ modes. The protection value is ±30 V when the power is on and ±15 V when the power is off.
The NI USB 6353 has four analog output channels, which provide measurements of 16-bits. These output channels provide digital signals and convert the signals into analog signals. These channels provide Output Resistance. The value of its output resistance is 0.2Ω. The current drive for the output of this high-quality device is ±5 mA. The output channels of the National Instruments NI USB-6353 work in different modes. One of the common waveform modes is the Periodic Waveform Regeneration.
Model | USB-6353 |
---|---|
Manufacturer | National Instruments |
Part Number | 781441-01 |
Type | Multifunction I/O Device |
Analog Input Channels | 32 single-ended or 16 differential |
Analog Output Channels | 4 |
Maximum Sample Rate | 1.25 MS/s |
Dimensions | 10.4 × 6.8 × 1.4 in. |
Weight | 3 lb 2 oz. |
Warranty | 2-3 Year Warranty |
USB-6353 Manual | User Manual and Maintenance Manual Available for Download |
Price | Contact a sales representative for a quote. |
Associated part numbers for the USB-6353:
150099A-02L, 150099B-02L, 150099C-02L, 781441-01, 787937-01
National Instruments USB-6353 Frequently Asked Questions
Question: What is the analog input absolute accuracy of the NI USB-6353?
Answer: The analog input absolute accuracy of the NI USB-6353 is 1520 uV.
Question: Which types of data transfers does the NI USB 6353 X Series device have?
Answer: The NI USB 6353 X Series device has USB Signal Stream and programmed I/O data transfers.
Question: What is the output FIFO size of the National Instruments NI USB-6353?
Answer: The output FIFO size of the National Instruments NI USB-6353 is 8,191 samples shared among channels used.
Question: What type of front connector does the USB-6353 NI have?
Answer: The USB-6353 NI has screw terminal front connectors.
