PCI-6512

Modular Systems > National Instruments > DIO Series

Part Number PCI-6512
Manufacturer/Brand National Instruments
Description PCI-6512 64-Channel, Bank-Isolated Digital I/O Device

Speak to a sales representative for pricing & lead time:


National Instruments PCI-6512 Digital I/O Device

The PCI-6512 (Part Number: 778968-01) can eliminate glitches, noise, and spikes on inputs that give debouncing to computerized switches and transfers due to its input filters that are programmable. For applications in loud mechanical conditions, this element is essential to evade fake readings that could be caused by commotion. The user can arrange the programmable input filters on each advanced line by setting the channel time like a flash.

The NI PCI-6512 utilizes NI-DAQmx estimation administrations programming, which is accessible for download from ni.com/downloads. The user can get to the full usefulness and best in class equipment innovation of the NI PCI 6512 device with the use of this driver software. NI-DAQmx innovation accelerates the user’s advancement with numerous highlights, including programmed code age to make design and programming simple. The NI PCI-6512 device takes full favorable position of key NI-DAQmx programming innovations, such as multithreaded spilling innovation for enhancements in I/O execution and convenience.

This model comes with an SCSI connector 100-pin high-density, which can interface with 100-stick strip links or protected links. For minimal effort unshielded availability, it is possible to utilize the R1005050 lace link with two CB-50LP or CB-50 connector squares (CB-100 pack). For protected availability, the user can utilize the SH100-100-F protected computerized I/O link with the SCB-100 connector square. The 37-stick D-Sub connector on the NI PCI 6512 Digital I/O Device interfaces with 37-stick connectors, including the SH37F-37M protected advanced I/O link with the CB-37FH DIN-rail-mountable connector square.

ModelPCI-6512
ManufacturerNational Instruments
Part Number778968-01
TypeDigital I/O Device
Input Lines0
Output Lines64 Source
IsolationBank
Maximum Input Voltage±30 VDC
Maximum Input Current12.5 mA/line
Propagation Delay75 μs
I/O Connector100-pin keyed female SCSI
Power Requirements+4.3 to +6.3 VDC, 20 mA/port
Dimensions5.54 in × 4.47 in.
Weight2.5 oz.
Driver SoftwareNI-DAQmx
WarrantyOne Year Warranty
PCI-6512 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PCI-6512 Frequently Asked Questions



Question: Which type of I/O connector does the NI PCI 6512 have?



Answer: The NI PCI 6512 has a 100-pin keyed female SCSI I/O connector.



Question: Which version of the PCI Local Bus Specification is the PCI 6512 compliant to?



Answer: The PCI 6512 is compliant to the PCI Local Bus Specification, Revision 2.2.



Question: Does the NI PCI-6512 require any accessories?



Answer: Yes, the NI PCI-6512 requires a Connector Block such as the SCB-100A(Part Number: 785024-01) and an I/O Cable such as the 1 m Type SH100-100-Flex Cable Assembly (Part Number: 185095-01) or the 2 m Type SH100-100-Flex Cable Assembly (Part Number: 185095-02).



Question: What is the maximum switching capacity for the PCI-6512?



Answer: The maximum switching capacity for the PCI-6512 is 350 mA (75 mA).

PCI-6512 Technical Specifications:


Manufacturer:National Instruments
Model:PCI-6512
Part Number:778968-01
Type:Digital I/O Device
Repair Evaluation:$150
