PCIe-6536

Modular Systems > National Instruments > DIO Series

Part Number PCIe-6536
Manufacturer/Brand National Instruments
Description PCIe-6536, 25 MHz maximum clock rate, Digital I/O Device
In Stock - Ships Today
In Stock | Ships 3-5 Days

Speak to a sales representative for pricing & lead time:


National Instruments PCIe-6536 Digital I/O Device

The National Instruments PCIe-6536 Digital I/O Device is a high-speed, 32-bit interface. This cost-effective device is built on a PCI Express bus technology. This model offers an easy way to interface with a broad range of digital applications, such as handshaking, chip testing, memory testing, pattern generation, logic vector capture, etc. With this model, the user can transfer data in four timing modes: Pattern I/O (synchronous), Handshaking I/O (asynchronous), on-demand (static I/O or unstrobed), and Burst handshaking (synchronous).

The National Instruments PCIe-6536 Digital I/O Device can be used with a variety of accessories to meet modern high-speed digital applications’ connectivity requirements. Connector block CB-2162 or the VHDCI high-density connector are a couple of such accessories. This Digital I/O Device comes equipped with an onboard sample clock (48 Hz to 25 MHz), which is configurable to 200 MHz. Since it is a PCI Express oriented high-speed device, the PCIe-6536 can be used for the generation and acquisition of larger digital waveforms because it can stream continuously at or less than 200 MB/s data. The NI PCIe-6536 can easily replace NI-6533/34 devices currently in operation.

To interface this device with already existing NI-6533/34 terminal blocks and fixtures, the user can utilize the 653x cable adapter. This Digital I/O Device is fully compatible with the NI-DAQmx driver and supports almost all the major programming software applications, including LabVIEW and Visual Studio .NET. With this model, users can interface digital devices and systems with PC-based applications directly. Moreover, this device can be used for communications control or transferring data to a digital network or devices.

ModelPCIe-6536
ManufacturerNational Instruments
TypeDigital I/O Device
Maximum Clock Rate25 MHz
Maximum Throughput100 MB/s
Data Channels32
Total Power6.1 W
Dimensions7.13 in. × 0.85 in. × 4.93 in.
Weight3.8 oz.
WarrantyOne Year Warranty
PCIe-6536 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PCIe-6536 Frequently Asked Questions



Question: What are the selectable voltage levels for the PCIe-6536?



Answer: The selectable voltage levels for the PCIe-6536 are 2.5 V and 3.3 V (5V compatible).



Question: Which timing modes does the NI PCIe-6536 have?



Answer: The NI PCIe-6536 has synchronous and asynchronous timing modes.



Question: How many Programmable Function Interface (PFI) channels does the PCIe-6536 have?



Answer: The PCIe-6536 has 6 PFI channels.



Question: What is the output impedance of the NI PCIe-6536?



Answer: The output impedance of the NI PCIe-6536 is 50 Ω, nominal.

PCIe-6536 Technical Specifications:


Manufacturer:National Instruments
Model:PCIe-6536
Type:Digital I/O Device
Repair Evaluation:$150
