National Instruments NI-5751B Digitizer Adapter Module for FlexRIO

The NI-5751B is an advanced Digitizer Adapter Module for FlexRIO from National Instruments. The manufacturer’s part number for this module is 784061-01. The NI 5751B is an updated revision of the NI 5751 module. Therefore, the NI-5751B has similar characteristics to the NI-5751. However, the NI-5751B has increased performance and efficiency. The NI-5751B can become a high-speed digitizer when paired with a PXI FPGA Module for FlexRIO. The NI-5751B supports a Kintex-7 FPGA. The NI-5751B module can be used for real-time processing and analog data streaming. High-speed ADCs can be paired with the NI-5751B for data processing and streaming. This module provides high-speed analog I/O for digitization, as well as digital I/O links to interface with external hardware.

The NI-5751B Digitizer Adapter Module for FlexRIO has 16, 26 MHz, analog inputs. These input channels are single-ended and DC-coupled. The input voltage range is -1 V to 1 V.  The NI-5751B provides parallel sampling up to 50 MS/s.  This module supports three clock sources with a frequency range of 30 MHz to 50 MHz. These clock sources include a 50 MHz onboard Clock, Sync Clock, or CLKIN. CLKIN connects via SMB connector and has a duty cycle of 45% to 55%. The NI-5751B module also has 16 digital terminals. Eight terminals are inputs while the other eight are output terminals. The digital terminals have VHDCI type connectors. The digital outputs have a maximum toggle frequency to 1 MHz maximum, with a pulse width of 10ns.

The NI-5751B Digitizer Adapter Module for FlexRIO is ideal for various applications. It is especially used in online data processing and streaming applications. This module is additionally widely used in time and frequency-domain applications, as well as medical and experimental applications.
