Part Number NI-5772
Manufacturer/Brand National Instruments
Description: NI-5772, 2.27 GHz, 2-Channel, Digitizer Adapter Module for FlexRIO
Lowest Price Guarantee
Fast Quote
Quoted Price
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing
2 year warrantyRefurbished
*What is Refurbished?
Quoted Price
Fully tested
2yr warranty
  Get Pricing

Need an Official Quote?


*Most customers receive their price in about 15 minutes.

Or speak to a sales representative for pricing & lead time:


National Instruments NI-5772 Digitizer Adapter Module for FlexRIO

The National Instruments NI-5772 is a 2-Channel, 12-Bit Digitizer Adapter Module for FlexRIO. This device can only work in conjunction with compatible PXI FPGA Modules: Kintex-7 and Virtex-5. The NI-5772 is available in two different configurations: AC-coupled (Part Number: 782097-01) and DC-coupled (Part Number: 782097-02). The DC-coupled version of this device comes with 358 MHz bandwidth and -1 V to 1 V analog input voltage range, whereas the AC-coupled version can operate over a broader analog input voltage range of -2 V to 2 V and has 2.27 GHz bandwidth.

The National Instruments NI 5772 module can acquire samples at rates up to 800 MS/s when using both of its channels. This device can acquire samples at up to 1.6 GS/s when utilizing only one of its channels. This module offers a variety of clock sources. It has a free running, 800 MHz internal sample clock. A 400 to 800 MHz frequency external sample clock can also be coupled with this device through the CLK IN front panel connector. In another arrangement, the internal sample clock of the NI-5772 can be locked to an externally located 10 MHz Reference clock through the REF IN connector.

This model has 2 SMA type Analog Input connectors, 1 SMA type CLK IN connector, 1 SMA type REF-IN connector, 1 SMA type TRIG (I/O) connector, and 1 AUX I/O port. The Aux port of the NI-5772 contains 8 DIO and 4 PFI channels and has overvoltage protection set at ±10 V.

ModelNI-5772
ManufacturerNational Instruments
Part Numbers782097-01, 782097-02
TypeDigitizer Adapter Module for FlexRIO
Voltage Input Channels2
Maximum Sample Rate1.6 GS/s
Analog Input Resolution12 bits
Dimensions5.1 x 0.8 x 4.7 in.
Weight23.3 oz.
WarrantyOne Year Warranty
NI-5772 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments NI-5772 Frequently Asked Questions



Question: What are the differences between the two part numbers for the NI-5772 module?



Answer: The first part number for the NI-5772, 782097-01, has AC analog input coupling, 2.27 GHz analog input bandwidth, and -2 V to 2 V analog input voltage range. The second part number, 782097-02, has DC analog input coupling, 358 MHz analog input bandwidth, and -1 V to 1 V analog input voltage range.



Question: Which connector block can be used with the NI 5772 to access the DIO and PFI signals?



Answer: The SCB-19 connector block can be used with the NI 5772 to access DIO and PFI signals.



Question: Which sampling modes are available on the NI-5772?



Answer: The NI-5772 has the following sampling modes available: TIS Enabled, Non-Multiplexed, TIS Disabled (default), TIS Enabled, Multiplexed to CH 1, and TIS Enabled, Multiplexed to CH 0.



Question: What is the total power of the NI 5772 for typical operation?



Answer: The total power of the NI 5772 is 5.1 W for typical operation.
