National Instruments PCI-6284 Multifunction DAQ

The National Instruments PCI-6284 (Part number: 779110-01) is an M Series Multifunction Data Acquisition Device. This model is structured with an analog and digital triggering arrangement. The NI PCI-6284 has one analog trigger. This trigger can operate at multiple analog manners. These modes include analog window triggering, analog edge triggering with hysteresis, and analog edge triggering mode. The analog trigger’s resolution is around 10 bits. The accuracy percentage of the analog trigger is ±1%. This analog trigger helps start and stop triggering. It can also be used as a reference trigger. The analog trigger can be further used for converting clocks, as well as sample clocks.

The NI PCI 6284 deals with analog inputs and associated digital I/O. This M Series Multifunction DAQ device has 2 general purpose counter/timers with 32-bit resolution. These counters/timers are used for edge counting-measurements and are also helpful to counter measure two edge separation. It is also feasible for period, semi period, and pulse counter measurements. The base clock precision is about 50 ppm. This device has an internal base clock frequency of 0.1 MHz, 20 MHz, and 80 MHz. The external base clock frequency ranges from 0 MHz to 20 MHz.

The National Instruments PCI 6284 Multifunction DAQ fulfills all requirements for electrical gear’s protection standards. These standards are used for control, measurements, and laboratory purposes. The NI PCI-6284 also meets the needs of EMC standards. National Instruments is dedicated to planning and developing products in an environment-friendly style.

ModelPCI-6284
ManufacturerNational Instruments
Part Number779110-01
SeriesM Series
TypeMultifunction DAQ
Analog Input Channels32 (18-Bit, 625 kS/s) or 16 differential
Analog Output Channels0
Digital Input/Output48
Timing I/O2 Counter/Timer I/O (32 bits, 80 MHz)
Frequency Generator Channels1
I/O Connectors2 68-pin VHDCI
Power Requirements+5 V, +3.3 V, +12 V, -12 V -- 0.03 A, 0.78 A, 0.40 A, 0.06 A
Dimensions4.2 in. × 6.1 in.
Weight0.35 lb.
Driver SoftwareNI-DAQmx, NI-DAQmx Base
WarrantyOne Year Warranty
PCI-6284 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PCI-6284 Frequently Asked Questions



Question: What is the input range of the NI PCI 6284?



Answer: The input range of the NI PCI 6284 is ±0.1 V, ±0.2 V, ±0.5 V, ±1 V, ±2 V, ±5 V, ±10 V.



Question: Which analog trigger modes are available on the NI PCI-6284?



Answer: The NI PCI-6284 has analog window triggering, analog edge triggering, and analog edge triggering with hysteresis.



Question: How often should the PCI-6284 be calibrated?



Answer: The PCI-6284 has a two year calibration interval.



Question: Which types of I/O connectors are on the PCI 6284?



Answer: There are two 68-pin VHDCI I/O connectors on the PCI 6284.
