National Instruments 783513-33 PXIe-8880 PXI Express Embedded Controller
The National Instruments 783513-33 (PXIe-8880) is an 8-core, high-performance PXI Express embedded controller powered by an Intel Xeon E5-2618L v3 processor running at a 2.3 GHz base frequency (3.4 GHz Intel Turbo Boost). Designed for high-density computational tasks, real-time signal processing, and RF record-and-playback applications, the controller routes PCI Express Gen 3 bus technology through one x16 and one x8 Gen 3 PCIe link to deliver up to 24 GB/s of total system bandwidth to the chassis backplane. System memory comes configured with 8 GB DDR4 standard, expandable up to 24 GB DDR4 across three SODIMM slots, paired with a high-reliability 240 GB Solid-State Drive (SSD) for primary storage and OS execution.
Front-panel connectivity features a comprehensive peripheral interface, including one IEEE 488 (GPIB) port for legacy instrument control, two high-speed USB 3.0 ports, four USB 2.0 ports, and two 10/100/1000BASE-T RJ45 Gigabit Ethernet ports for network connectivity and system management. External video output is supported via a DisplayPort 1.2 connector capable of driving high-resolution displays. Additional timing, synchronization, and system monitoring features include a dedicated SMB connector for hardware watchdog and triggering functions, alongside Intel Active Management Technology (AMT) for out-of-band remote administration, diagnostics, software updates, and remote booting without requiring physical access.
Hardware security and device authentication are reinforced by an integrated Trusted Platform Module (TPM v1.2), which protects cryptographic keys and platform credentials against software-based vulnerabilities. Weighing 2.33 kg and occupying three PXI Express system slots, the PXIe-8880 integrates into any compatible PXI Express chassis. By combining server-class multi-core processing with integrated system peripherals into a single embedded controller slot, the module maximizes available peripheral chassis slots for dedicated measurement, data acquisition, and instrument hardware.
Part Number |
783513-33 |
|---|---|
Model Name |
PXIe-8880 |
Part Type |
PXI Express Embedded Controller |
Processor |
Intel Xeon E5-2618L v3 |
Processor Cores |
8 |
Processor Frequency |
2.3 GHz |
Standard Memory |
8 GB |
Maximum Memory |
24 GB |
System Bandwidth |
24 GB/s |
Standard Storage |
240 GB, SSD |
