PXIe-8842
Modular Systems > National Instruments > PXI Controllers
| Description: | PXIe-8842, 8 GB Memory, 4 PXIe Expansion Slots, 6 Core PXI Controller |
Need an Official Quote?
Or speak to a sales representative for additional information:
Phone:1-800-915-6216
Email:sales@apexwaves.com
National Instruments PXIe-8842 PXI Controller
The PXIe-8842 (Part Numbers: 787882-00, 787882-01, 787882-0118, 787882-33, 788816-01, 788816-0118) is an advanced embedded controller designed by National Instruments for PXI systems and engineered to handle processor-intensive tasks in modular instrumentation and data acquisition environments. It has a powerful Intel® CoreTM i5-11500HE CPU, which is augmented by a 12 MB Smart Cache, ensuring fast processing for demanding applications.
This controller has 8 GB of standard memory, which can be expanded to 16 GB by using single-channel DDR4-3200 MHz non-ECC SODIMM modules. A spacious 512 GB (or greater) M.2 NVMe SSD meets storage requirements, providing quick data access and plenty of room to store critical information.
With two i225 Ethernet ports that support different speeds (10M/100M/1000M/2.5G Base-T), one mini-GPIB port for IEEE 488 control, and one DisplayPort 1.4 port for video output, the PXIe-8842 enables seamless connectivity. In addition, it has four Hi-Speed USB 2.0 Type-A ports, two SuperSpeed USB 3.0 Type-A ports, one Thunderbolt 4 Type-C port, and one DB-9 serial port for flexible peripheral interfacing.
The PXIe-8842 controller guarantees effective data transfer within the PXI system since it has a PCI Express Link Speed of 5.0 GT/s and PXI Express configurations of x4 and x8. It also offers a PXI Trigger Bus Input/Output via a single SMB connector, enhancing synchronization capabilities across instruments.
The controller may run at +3.3V, +5V, +12V, and +5Vaux voltages. Its maximum current can vary from 2.6A to 7.1A, which guarantees steady operation within predetermined bounds.
To meet the needs of a variety of application scenarios, this controller supports a number of operating systems, including Linux RT, Windows 10 IoT, and Windows 11 IoT. An additional degree of security is provided by the optional Trusted Platform Module (TPM) 2.0, which is offered in versions for both the Chinese and international markets.
The PXIe-8842, which was constructed in accordance with industry standards, occupies one system slot and three controller expansion slots in PXI Express Specification 1.0 systems with ease. Its compact, lightweight design, weighing only 753g (1.66 lb) typical, makes it ideal for space-constrained environments.
The PXIe-8842 is built to work in a variety of environmental conditions, with an operating temperature range of 0°C to 55°C and a relative humidity range of 10% to 90%. Its sturdy construction guarantees robustness against half-sine, random vibrations within predetermined boundaries, and operating shocks up to 30 g peak.
| Model Name | PXIe-8842 |
|---|---|
| Part Numbers | 787882-00, 787882-01, 787882-0118, 787882-33, 788816-01, 788816-0118 |
| CPU | Intel® CoreTM i5-11500HE Processor |
| Memory | 8 GB DDR4-3200 MHz RAM (Expandable to 16 GB) |
| Storage | 512 GB (or higher) M.2 NVMe SSD |
| Video | 1 DisplayPort 1.4 |
| Ethernet | 2 i225 ports, 1588, 10M/100M/1000M/2.5G Base-T |
| USB Ports | 4 Hi-Speed USB 2.0 Type-A, 2 SuperSpeed USB 3.0 Type-A |
| Expansion Slots | 4 PXI Express slots (1 system, 3 controller) |
| Operating System | Windows 10 IoT, Windows 11 IoT, Linux RT |
| Trusted Platform Module | Optional TPM 2.0 (Infineon/ST or NationsTech) |
| Dimensions | Four-wide 3U PXI Express module |
| Weight | 753 g (1.66 lb) typical |
| Operating Temperature | 0 °C to 55 °C |
| Operating Humidity | 10% to 90%, non-condensing |
National Instruments PXIe-8842 Frequently Asked Questions
Question: Why does the PXIe-8842 have different part numbers?
Answer: The different part numbers represent different versions/models of the PXIe-8842 that vary by the operating system (OS) used. The part numbers and their specifications are as follows: 787882-00: no OS, 787882-01: Windows 10 64-Bit, 787882-0118 Windows 10 64-Bit China, and 787882-33 LabVIEW RT.
Question: What ports does the PXIe-8842 feature?
Answer: This PXI Controller includes two 10/100/1000/2500 BASE‑T Gigabit Ethernet ports, four Hi‑Speed USB ports, two USB 3.0 ports, an RS-232 serial port, a DisplayPort 1.4, a mini-GPIB port, and a thunderbolt port.
Question: What is the difference between the PXIe-8842 and the PXIe-8822?
Answer: The PXIe-8842 is more powerful than the PXIe-8822. It has a Core i5 CPU and 12 MB cache, compared to the PXIe-8822's Core i3 CPU and 8 MB cache. Furthermore, the PXIe-8842 has all the ports on the PXIe-8822 plus an additional two USB 2.0 ports, a mini-GPIB port, and a thunderbolt port.
Question: Can I connect a mouse and keyboard to the PXIe-8842 controller?
Answer: Yes. However The PXIe-8842 has no PS/2 connector, and you need to use a USB Y-splitter cable or a similar device, to connect both a PS/2 mouse and PS/2 keyboard.
Why Buy From Apex Waves:
"The business transaction was super easy and friendly."
"Hand carrying parts to fedex directly to make sure I get them overnight. Great service"
"They were very helpful to get me the test equipment that I need."
PXIe-8842
Modular Systems > National Instruments > PXI Controllers
PXIe-8842, 8 GB Memory, 4 PXIe Expansion Slots, 6 Core PXI Controller
1-800-915-6216
- Description
- Technical Specifications
- FAQ
- Manuals & PDFs
National Instruments PXIe-8842 PXI Controller
The PXIe-8842 (Part Numbers: 787882-00, 787882-01, 787882-0118, 787882-33, 788816-01, 788816-0118) is an advanced embedded controller designed by National Instruments for PXI systems and engineered to handle processor-intensive tasks in modular instrumentation and data acquisition environments. It has a powerful Intel® CoreTM i5-11500HE CPU, which is augmented by a 12 MB Smart Cache, ensuring fast processing for demanding applications.
This controller has 8 GB of standard memory, which can be expanded to 16 GB by using single-channel DDR4-3200 MHz non-ECC SODIMM modules. A spacious 512 GB (or greater) M.2 NVMe SSD meets storage requirements, providing quick data access and plenty of room to store critical information.
With two i225 Ethernet ports that support different speeds (10M/100M/1000M/2.5G Base-T), one mini-GPIB port for IEEE 488 control, and one DisplayPort 1.4 port for video output, the PXIe-8842 enables seamless connectivity. In addition, it has four Hi-Speed USB 2.0 Type-A ports, two SuperSpeed USB 3.0 Type-A ports, one Thunderbolt 4 Type-C port, and one DB-9 serial port for flexible peripheral interfacing.
The PXIe-8842 controller guarantees effective data transfer within the PXI system since it has a PCI Express Link Speed of 5.0 GT/s and PXI Express configurations of x4 and x8. It also offers a PXI Trigger Bus Input/Output via a single SMB connector, enhancing synchronization capabilities across instruments.
The controller may run at +3.3V, +5V, +12V, and +5Vaux voltages. Its maximum current can vary from 2.6A to 7.1A, which guarantees steady operation within predetermined bounds.
To meet the needs of a variety of application scenarios, this controller supports a number of operating systems, including Linux RT, Windows 10 IoT, and Windows 11 IoT. An additional degree of security is provided by the optional Trusted Platform Module (TPM) 2.0, which is offered in versions for both the Chinese and international markets.
The PXIe-8842, which was constructed in accordance with industry standards, occupies one system slot and three controller expansion slots in PXI Express Specification 1.0 systems with ease. Its compact, lightweight design, weighing only 753g (1.66 lb) typical, makes it ideal for space-constrained environments.
The PXIe-8842 is built to work in a variety of environmental conditions, with an operating temperature range of 0°C to 55°C and a relative humidity range of 10% to 90%. Its sturdy construction guarantees robustness against half-sine, random vibrations within predetermined boundaries, and operating shocks up to 30 g peak.
| Model Name | PXIe-8842 |
|---|---|
| Part Numbers | 787882-00, 787882-01, 787882-0118, 787882-33, 788816-01, 788816-0118 |
| CPU | Intel® CoreTM i5-11500HE Processor |
| Memory | 8 GB DDR4-3200 MHz RAM (Expandable to 16 GB) |
| Storage | 512 GB (or higher) M.2 NVMe SSD |
| Video | 1 DisplayPort 1.4 |
| Ethernet | 2 i225 ports, 1588, 10M/100M/1000M/2.5G Base-T |
| USB Ports | 4 Hi-Speed USB 2.0 Type-A, 2 SuperSpeed USB 3.0 Type-A |
| Expansion Slots | 4 PXI Express slots (1 system, 3 controller) |
| Operating System | Windows 10 IoT, Windows 11 IoT, Linux RT |
| Trusted Platform Module | Optional TPM 2.0 (Infineon/ST or NationsTech) |
| Dimensions | Four-wide 3U PXI Express module |
| Weight | 753 g (1.66 lb) typical |
| Operating Temperature | 0 °C to 55 °C |
| Operating Humidity | 10% to 90%, non-condensing |
National Instruments PXIe-8842 Frequently Asked Questions
Question: Why does the PXIe-8842 have different part numbers?
Answer: The different part numbers represent different versions/models of the PXIe-8842 that vary by the operating system (OS) used. The part numbers and their specifications are as follows: 787882-00: no OS, 787882-01: Windows 10 64-Bit, 787882-0118 Windows 10 64-Bit China, and 787882-33 LabVIEW RT.
Question: What ports does the PXIe-8842 feature?
Answer: This PXI Controller includes two 10/100/1000/2500 BASE‑T Gigabit Ethernet ports, four Hi‑Speed USB ports, two USB 3.0 ports, an RS-232 serial port, a DisplayPort 1.4, a mini-GPIB port, and a thunderbolt port.
Question: What is the difference between the PXIe-8842 and the PXIe-8822?
Answer: The PXIe-8842 is more powerful than the PXIe-8822. It has a Core i5 CPU and 12 MB cache, compared to the PXIe-8822's Core i3 CPU and 8 MB cache. Furthermore, the PXIe-8842 has all the ports on the PXIe-8822 plus an additional two USB 2.0 ports, a mini-GPIB port, and a thunderbolt port.
Question: Can I connect a mouse and keyboard to the PXIe-8842 controller?
Answer: Yes. However The PXIe-8842 has no PS/2 connector, and you need to use a USB Y-splitter cable or a similar device, to connect both a PS/2 mouse and PS/2 keyboard.
PXIe-8842 PDF Manuals & Diagrams
PXIe-8842 PDF Manuals
PXIE 8842 DECLARATION OF CONFORMITY.PDF
PXIE 8842 LETTER OF VOLATILITY.PDF
