National Instruments PXI-5412 PXI Waveform Generator

The National Instruments PXI-5412 Waveform Generator utilizes computerized interpolation to enhance the output signal nature of smooth waveforms. Each digital-to-analog converter produces reconstruction images in the recurrence domain because of the conversion process. This model comes in three configurations: the PXI-5412 with 8 MB memory (Part Number: 779176-01), the PXI-5412 with 32 MB memory (Part Number: 779176-02), and the PXI-5412 with 256 MB memory (Part Number: 779176-03). The device has a maximum bandwidth of 20 MHz, and has an update rate of up to 100 MS per second.

By utilizing a high-order filter like low cutoff recurrence, the imperfections of the channel, including passband ripple and nonlinear phase, significantly influence generator execution. The National Instruments PXI-5412 Waveform Generator utilizes computerized interpolation to build the successful testing rate, migrating the reconstruction images to higher frequencies. By doing so, the required simple channel cutoff recurrence is expanded, which decreases channel twisting impacts. With the mix of digital interpolation and analog filtering, the PXI-5412 Waveform Generator can have excellent passband flatness and improved image dismissal, which guarantees a low-distortion output signal. Sharp waveforms, such as square waves, pulse, and video signals, interpolation and analog filtering, can be disabled, resulting in quick rise/fall times and low pulse deviation (overshoot, undershoot, and so on).

The device is run using the NI-FGEN driver software which is compatible with software packages/application development environments (ADEs) such as LabVIEW, LabWindows/CVI, or Measurement Studio. It has a recommended warm-up time of 15 minutes and should be externally calibrated at least once every 2 years.

The National Instruments PXI-5412 can be customized to sequence and loop an arrangement of waveforms. A few strategies can be utilized to progress through the sequence of waveforms. In some cases, the duration of every waveform is known ahead of time, so the Waveform Generator can be modified to loop every waveform a predefined number of times. It has a recommended operating temperature range of 0 ºC to 55 ºC, and a storage temperature range of -25 ºC to 85 ºC.

PXI-5412 Mature Status has been announced by National Instruments, but the waveform generator will still be available for purchase and repairs by Apex Waves.

The PXI-5412 is available to be calibrated. While the recommended calibration period for individual parts varies, most parts should be calibrated either annually or every two years to ensure accuracy. If you need the PXI-5412 calibrated, Apex Waves provides options. We offer high-quality NIST accredited calibrations through a 3rd party, with an average turnaround time of 1 to 2 weeks. When you order the PXI-5412 with us, you can request basic (unaccredited) in-house calibration that will calibrate the part to the manufacturer specifications prior to being shipped. Call or email us today for more information about calibrating the PXI-5412!

ModelPXI-5412 (779176-01, 779176-02, 779176-03)
ManufacturerNational Instruments
TypePXI Waveform Generator
Maximum Bandwidth20 MHz
Maximum Update Rate100 MS/s
Onboard Memory Size8, 32, or 256 MB
Output Channels1
WarrantyThree Year Warranty
PXI-5412 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for PXI-5412:

188524D-14, 188524G-14L, 188524G-16L, 188524J-14L, 192273A-01, 192273B-01, 192273C-01L, 192273D-01L, 192274B-03, 192273E-01L, 192274C-01, 192273F-01L, 192274C-02, 192274-02, 192274C-03, 192274A-01, 192274D-01L, 192274A-02, 192274D-02L, 192274A-03, 192274D-03L, 192274B-01, 192274E-01L, 192274B-02, 192274E-02L, 192274E-03L, 192274F-01L, 192274F-02L, 192274F-03L, 192274G-01L, 192274G-02L, 192274G-03L, 192274H-01L, 192274H-02L, 192274H-03L, 200026A-01, 779176-01, 779176-02, 779176-03

National Instruments PXI-5412 Frequently Asked Questions



Question: How can I read a function generator from the PXI-5412?



Answer: The PXI-5412 is a function/arbitrary waveform generator and it cannot read anything. It is an output only device. To check the output, you can connect it to a scope.



Question: What is the sampling rate of the PXI 5412?



Answer: The PXI 5412 has a 100 MS/s sampling rate, 400 MS/s with interpolation.



Question: What is the sine wave generation range on the NI PXI-5412?



Answer: The NI PXI-5412 has a 20 MHz sine wave generation.
