National Instruments PXI-7813R PXI Digital Reconfigurable I/O Module

The NI PXI-7813R Digital Reconfigurable I/O Module (Part Number: 779362-01) has 160 bidirectional DIO lines and a Virtex-II XC2V3000 FPGA. The distinction in ground potential between two instruments associated with a similar building power framework is commonly about 1 and 100 mV. This distinction can be considerably higher if control appropriation circuits are improperly associated. If a grounded signal source is improperly estimated, this difference may show up as an estimation mistake. The association guidelines for grounded signal sources are intended to wipe out this ground potential distinction from the measured flag.

This model offers a DIFF input mode, where the NI PXI-7813R measures the distinction between the positive and negative sources of inputs. DIFF input mode is perfect for estimating ground-referenced signals from different gadgets. When utilizing DIFF input mode, the input signal interfaces with the positive contribution of the instrumentation enhancer and its reference signal, or return, associates with the negative contribution of the instrumentation intensifier. Differential signal associations decrease noise pickup and increment common-mode noise rejection. Differential signal associations also permit input signals to float inside the common-mode limits of the instrumentation intensifier.

The user can arrange the PXI-7813R channels in software for RSE or NRSE input modes. They can also utilize the RSE input mode for floating signal sources. For this situation, the NI PXI-7813R gives the reference ground point to the external signal. The NRSE input mode can be used for ground-referenced signal sources. For this situation, the external signal supplies its own reference ground point and the PXI-7813R does not need to supply one.

PXI-7813 Obsolete Status has been announced by National Instruments, but the module will still be available for purchase and repairs by Apex Waves.

ModelPXI-7813R (779362-01)
ManufacturerNational Instruments
SeriesR Series
TypePXI Digital RIO Module
FPGAVirtex-II 3M Gate
Digital I/O160
Dimensions6.3 x 3.9 in.
Weight152 g.
WarrantyOne Year Warranty
PXI-7813R ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-7813R Frequently Asked Questions



Question: What does the PXI-7813R require for operation?



Answer: For operation, the PXI-7813R requires one cable and one connector block.



Question: What is the minimum pulse width of the NI PXI-7813R?



Answer: The minimum pulse width of the NI PXI-7813R is 25 ns for the input and 12.5 ns for the output.



Question: What is the embedded block RAM capacity for the PXI-7813R?



Answer: The embedded block RAM capacity for the PXI-7813R is 1,728 kbits.



Question: Where can I find the NI PXI 7813R user manual?



Answer: The NI PXI 7813R user manual is available on apexwaves.com.
