SCXI-1317 National Instruments Terminal Block | Apex Waves | Image SCXI-1317 National Instruments Terminal Block | Apex Waves | ImageSCXI-1317
SCXI-1317 National Instruments Terminal Block | Apex Waves | Image
SCXI-1317 National Instruments Terminal Block | Apex Waves | Image
SCXI-1317 New

SCXI-1317

5/5 | 10 ratings

Modular Systems > National Instruments > SCXI

Part Number SCXI-1317
Manufacturer/Brand National Instruments
Description: SCXI-1317 24-Channel Terminal Block
Lowest Price Guarantee
Fast Quote
Quoted Price
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing
2 year warrantyRefurbished
*What is Refurbished?
Quoted Price
Fully tested
2yr warranty
  Get Pricing

Need an Official Quote?


*Most customers receive their price in about 15 minutes.

Or speak to a sales representative for pricing & lead time:


National Instruments SCXI-1317 Terminal Block

The SCXI-1317 (Part Number: 777687-17) is a Front-Mounting Terminal Block created for use with the SCXI-1521 and SCXI-1521B quarter-bridge Strain Gage Input Modules. The SCXI 1317 has 24 channels; this Terminal Block offers three screw terminals for every quarter-bridge strain gage channel. These channels include: excitation+, analog in, and quarter-bridge. The NI SCXI-1317 is shielded to ensure precise signal connections and is autodetectable via software.

The following types of hardware are required to operate the SCXI-1317: the SCXI-1521 or SCXI-1521B module, an SCXI or PXI/SCXI combination chassis, and the necessary cabling, cable adapter, and quarter-bridge strain gauges as needed for the user’s specific application. When making quarter-bridge signal connections with a 2- or 3-wire strain gauge if the transducer is shielded, then the user can link the shield to the GND link on the SCXI 1317.

To link the signal to the NI SCXI-1317 Terminal Block, the user first must unscrew the screws on the top cover and take off the top cover. They can then loosen the strain-relief screws and take off the strain-relief bar. Afterwards, strip the insulation of the signal wire (no more than 0.28 inches). Next, the user must run the signal wires through the strain-relief opening. If it is required, the user can also add insulation or padding. The last step is to place the stripped end of the signal wires completely into the terminal. The user should ensure that there is not any bare wire sticking out past the screw terminal because exposed wire increases the chance of a short circuit and therefore circuit failure.

SCXI-1317 Obsolete Status has been announced by National Instruments, but will still be available for purchase and repairs by Apex Waves.

ModelSCXI-1317
Part Number777687-17
ManufacturerNational Instruments
TypeTerminal Block
Channels24
For Use With:SCXI-1521/B Modules
Maximum Working Voltage42 Vrms, Installation Category I
Dimensions5.9 in. by 3.1 in. by 1.2 in.
WarrantyOne Year Warranty
SCXI-1317 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments SCXI-1317 Frequently Asked Questions



Question: What should I do if the transducer is shielded on the SCXI-1317?



Answer: If the transducer is shielded on the SCXI-1317, connect the shield to the GND connection.



Question: How do you use the SCXI 1317 to connect quarter-bridge strain gauges?



Answer: To connect the quarter-bridge strain gauges using the SCXI 1317, you need to connect it to the SCXI-1521/B module.



Question: What size strain gauge can you use with the NI SCXI-1317 to make quarter-bridge signal connections?



Answer: You can use either a 2- or 3-wire strain gauge with the NI SCXI-1317 to make a quarter-bridge signal connection.

SCXI-1317 Driver Downloads

  SCXI-1317 Driver Packages


SCXI-1317 Technical Specifications:

Manufacturer:National Instruments
Model:SCXI-1317
Part Number:777687-17
Series:SCXI Series
Type:Terminal Block
Repair Evaluation:$150
