Part Number PXI-8420-16
Manufacturer/Brand National Instruments
Description: PXI-8420/16, 16-Port, RS-232 Interface
In Stock | Ships Today
Fast Quote
Quoted Price
Lowest Price Guarantee
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing
2 year warrantyRefurbished
*What is Refurbished?
Quoted Price
Fully tested
2yr warranty
  Get Pricing

Need an Official Quote?


*Most customers receive their price in about 15 minutes.

Or speak to a sales representative for pricing & lead time:


National Instruments PXI-8420/16 RS-232 Interface

The NI PXI-8420/16 (Part Number: 777733-16) module is an RS-232 Interface with 16 ports available for use. The NI PXI-8420/16 RS-232 Interface offers 2000 V of optical confinement with two or four ports. This is a superset of RS232 and develops the capacities. RS232 was made to address the multi-drop constraint of RS232, permitting up to 32 gadgets to impart through a similar information line. Any of the slave gadgets on an RS232 bus can communicate with the other 32 slave gadgets without experiencing a master gadget.

In the NI PXI-8420/16 RS-232 Interface, when the "fetch" of various records has played out, the DMA procedure has begun and completed for each record. At the point when information is procured consistently rather than numerous enlist, the DMA procedure has begun and ended with the call of the "Bring" work. The differential transmission permits rates of up to 10 Mbps, over separations of up to 1.3 km. Two signals are utilized to transmit and two to get, notwithstanding the ground, which is typically associated with the link shield. In each combination, the transmission signal and its supplement travel. In the receiver, the first signal is received by subtracting one from the other. This system enormously diminishes the commotion created in the line, since it is prompted similarly in the two lines of the match and is eventually dropped. This kind of transmission ought to dependably be done on the "contorted sets" type link.

ModelPXI-8420/16
Part Number777733-16
ManufacturerNational Instruments
TypePXI Serial Interface Module
Ports16
Supported Serial ProtocolsRS-232
Maximum Transfer Rate115.2 kb/s
Dimensions3.94 x 6.37 in.
I/O Connector100-pin SCSI
WarrantyOne Year Warranty
PXI-8420/16 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-8420/16 Frequently Asked Questions



Question: Which signals are compatible with the PXI-8420/16?



Answer: On the PXI-8420/16, ports 1-8 are compatible with all signals, while ports 9-16 are only compatible with RXD, TXD, GND, RTS, and CTS signals.



Question: What is the maximum current for the NI PXI-8420/16?



Answer: The maximum current for the NI PXI-8420/16 is 1,000 mA.



Question: What is the data line ESD protection (HBM) for the PXI-8420/16?



Answer: The PXI-8420/16 has a data line ESD protection (HBM) of 15 kV.



Question: How large is the FIFO of the NI PXI-8420/16 device?



Answer: The FIFO of the NI PXI-8420/16 device is 64 B.
