National Instruments PXI-6071E Multifunction DAQ
The NI PXI-6071E is a PXI Multifunction DAQ (Part Number: 777676-01), which has an instrument class estimation and amplifier that ensures settlement times in all profits.
This model offers the following features:
- 64 single-ended or 32 differential analog input channels with an input resolution of 12 bits, and a maximum sample rate of 1.25 MS per second.
- 2 analog output channels with a resolution of 12 bits.
- 8 digital I/O channels with a 5 V/TTL compatibility.
- FIFO buffer size of 512 S and 3 DMA channels.
- PFI Lines: These are eight programmable function input (PFI) lines that can be utilized for software-controlled routing of interboard and intraboard digital and timing signals.
- RTSI or PXI Trigger Bus: This feature is used to share timing and control motions amongst gadgets and synchronize operations.
- RSE Mode: Along with differential and non-referenced single-ended modes, NI full-highlighted E Series gadgets provide referenced single-ended (RSE) mode to be utilized with floating signal sources in applications with more than eight channels. Onboard Temperature Sensor: This is included for checking the operation temperature of the gadget to guarantee that it is working inside the predetermined range.
- Elite Driver Engine: Software-timed single-point input (typically utilized as a part of control loops) with NI-DAQ, the module accomplishes rates as high as 50 kHz. NI-DAQ likewise conveys the greatest I/O framework throughput with a multithreaded driver.
- Scaled Channels: The user can effortlessly scale voltage information into the best possible designed units by utilizing the NI-DAQ Measurement Ready virtual channels and picking from a variety of basic sensors and signals or making a unique, customized scale.
- A 100-pin female 0.050 D-type connector.
- Automatic Code Generation: DAQ Assistant is an intelligent guide that aids the user with arranging, assessing, and programming estimation tasks and producing the required code for use with LabVIEW, LabWindows/CVI, or Measurement Studio.
The device weighs 4.1 oz. and measures 6.3 x 3.9 in. in physical dimensions.
The PXI-6071E is considered obsolete by National Instruments and is no longer available directly from their site, but the Multifunction DAQ will still be available for purchase and repairs in perpetuity by Apex Waves.
| Model | PXI-6071E |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 777676-01 |
| Series | Legacy E Series |
| Type | Multifunction DAQ |
| Analog Input Channels | 64 Single-Ended, 32 Differential |
| Analog Output Channels | 2 |
| Digital I/O Channels | 8 |
| Analog Input Resolution | 12 Bits |
| Maximum Sample Rate | 1.25 MS/s |
| I/O Connector | 100-Pin Female 0.050 D-Type |
| Power at I/O Connector | +4.65 to +5.25 VDC at 1 A |
| Input Coupling | DC |
| Operating Temp Range | 0 to 55 °C |
| Storage Temp Range | –20 to 70 °C |
| Dimensions | 6.3 x 3.9 in. (16 cm × 10 cm) without Connectors |
| Weight | 7.5 oz (214 g) |
| PXI-6071E Manual | User Manual and Maintenance Manual Available for Download |
| Price | Request a Quote |
Associated part numbers for PXI-6071E:
National Instruments PXI-6071E Frequently Asked Questions
Question: Where can I view the pinout for the PXI-6071E?
Answer: The pinout for this module can be viewed in the PXI-6071E manual, which can be found under the "Manuals & PDFs" tab
Question: What is the output rate of the PXI-6071E?
Answer: The National Instruments DAQ has an output rate of 1 MS/s.
Question: What is the measurement sensitivity?
Answer: The NI PXI-6071E has a measurement sensitivity of 0.009 mV.
Question: What is the input range of the PXI-6071E?
Answer: The DAQ has an input range of ±0.05 to ±10 V.
PXI-6071E PDF Manuals
