National Instruments NI-5732 Digitizer Adapter Module for FlexRIO

The NI‑5732 (Part number: 781658-02) is a Digitizer Adapter Module for FlexRIO manufactured by National Instruments. This module fulfills the monitoring requirements and parameters for EMC. These parameters and requirements are intended to deliver reasonable shield against harmful interference. The NI 5732 is suitable for industrial locations. The NI-5732 module has an AUX I/O connector and accepts a standard HDMI cable. The AUX connector uses 2.1 W of power. The connectors on the front panel include HDMI, BNC, and SMB. The physical dimensions are 5.1 x 0.8 x 4.7 inches. The NI-5732 weighs around 313 grams.

The NI‑5732 supports software and comes with component-level IP (CLIP) options. The CLIP offers admittance to the NI 5732 physical I/O. This CLIP provides access to two analog input channels. The CLIP also comprehends an engine to program the A/D Convertor and clock. This is accomplished through programmed settings for an easier instrument setup. It can also be done through a data signal and raw SPI address. This is suitable for advanced setup. This Digitizer Adapter Module for FlexRIO also offers eight bidirectional DIO channels and four bidirectional PFI channels. Moreover, there is an input clock selector, which can be aligned to perform at multiple settings.

14-bit analog with input data is accessed in the LabVIEW FPGA Module by using a U16 data type. The NI-5732 is fully compatible with PXI systems. The NI-5732 has an operational vibration and shock of 30g peak with 11ms pulse.

ModelNI-5732
ManufacturerNational Instruments
Part Number781658-02
TypeDigitizer Adapter Module for FlexRIO
Voltage Input Channels2
Maximum Sample Rate80 MS/s
Analog Input Resolution14 bits
Dimensions5.1 x 0.8 x 4.7 in.
Weight11.0 oz.
WarrantyOne Year Warranty
NI-5732 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments NI-5732 Frequently Asked Questions



Question: Why can’t I see my NI-5732 module when I open NI MAX?



Answer: The NI-5732 module requires NI-FlexRIO Driver 15.5 or later or the NI FlexRIO Adapter Module Support 2.1 or later.



Question: Which type of FPGA is compatible with the NI 5732?



Answer: Kintex-7 and Virtex-5 FPGAs are compatible with the NI 5732.



Question: What does the internal clock on the NI-5732 control?



Answer: The internal clock on the NI-5732 controls the sample rate and various timing functions.



Question: What is the ADC part number for the NI 5732?



Answer: The ADC part number for the NI 5732 is AD9258BCPZ-80.
