Part Number PXI-6562
Manufacturer/Brand National Instruments
Description: PXI-6562, 16-Channel, PXI Digital Waveform Instrument
Request for Availablility
Fast Quote
Quoted Price
Lowest Price Guarantee
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing
2 year warrantyRefurbished
*What is Refurbished?
Quoted Price
Fully tested
2yr warranty
  Get Pricing

Need an Official Quote?



Or speak to a sales representative for pricing & lead time:


National Instruments PXI-6562 PXI Digital Waveform Instrument

The National Instruments PXI-6562 (Part numbers: 778994-01, 778994-02, and 778994-03) is a 200 Mb/s Digital Waveform Instrument for interfacing to LVDS electronics. This module highlights 100 clock rates individually. Single and double-data-rate modes are included and offer 16 channels with per-channel direction control (in single-data rate mode) and a deep onboard memory with triggering and pattern sequencing. They can be used with the National Instruments Digital Waveform Editor, an interactive programming apparatus for making and altering computerized waveforms. With the SMC, the user can make mixed-signal test frameworks with digitizers, arbitrary waveform generators, and other digital waveform generator/analyzers. Additionally, the user can synchronize numerous computerized gadgets to build low-skew multichannel frameworks for interfacing to high-pin-count digital ICs and electronics.

The new modules are built on the common Synchronization and Memory Core (SMC) architecture, so they firmly synchronize with other SMC-based measured instruments, such as the recently released 200 MS/s PXI digitizer and arbitrary waveform generator. Engineers additionally can utilize the SMC synchronization innovation to assemble high-channel-count frameworks by utilizing numerous LVDS modules. To rapidly make test applications with the NI PXI-6562, specialists can use two capable programming instruments: Express VIs in the NI LabVIEW 7.1 graphical improvement environment and the NI Digital Waveform Editor for making and altering test vectors.

The PXI-6562 allows the user to make and edit patterns interactively with the Digital Waveform Editor, import existing waveforms into National Instruments LabVIEW from VHDL reproduction and spreadsheet apparatuses in Value Change Dump (VCD) or ASCII groups, create new waveforms utilizing built-in fill designs, and edit waveforms intelligently in the UI.           .

PXI-6562 Obsolete Status has been declared by National Instruments, but the instrument will still be available for purchase and repairs by Apex Waves.

ModelPXI-6562 (778994-01, 778994-02, 778994-03)
ManufacturerNational Instruments
TypePXI Digital Waveform Instrument
Onboard Clock Frequency Range48 Hz to 200 MHz
Channels16
Onboard Memory2, 16, or 128 Mb/channel
Dimensions8.5 x 0.8 x 5.1 in.
Weight12 oz.
WarrantyOne Year Warranty
PXI-6562 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-6562 Frequently Asked Questions



Question: What is the difference between the three part numbers for the PXI-6562?



Answer: The three part numbers for the PXI-6562 each have a different onboard memory size. The 778994-01 has 2 Mb/channel, the 778994-02 has 16 Mb/channel, and the 778994-03 has 128 Mb/channel.



Question: What is the maximum date rate of the NI PXI-6562?



Answer: The NI PXI-6562 has a maximum date rate of 400 Mb/s.



Question: What is the input impedance of the PXI-6562?



Answer: The PXI-6562 has an input impedance of 100 Ohms.



Question: What is the maximum power requirement for the NI PXI-6562?



Answer: The maximum power requirement for the NI PXI-6562 is 16.4 W.
