National Instruments 763061-03 X2 GPIB Cable
This National Instruments 763061-03 cable is a 4-meter X2 GPIB cable designed to connect test & measurement systems to IEEE 488 compliant instruments. It features dual-end connectivity via a 24-pin IEEE 488 connector on each end, including female and male connectors on both sides. These can form a daisy chain by stacking the cable ends together so that as many GPIB devices are connected in series, they do not require the purchase of additional hardware adapters. This type of connection is ideal for use in laboratories and/or automated test system applications that have two or more instruments communicating using one GPIB interface card or controller.
The 'X2' in the National Instruments model number for this cable indicates that this cable has the connectors for male and female ends built into the same connector on each end of the cable. This allows users to simply stack the instruments and/or interfaces on top of one another. The length of this cable allows engineers enough room to place their rack-mounted controllers near the bench-mounted instruments or other peripherals that may be required for testing. The double shielding used in conjunction with the shielded plugs and receptacles at each end helps to reduce Electromagnetic Interference (EMI) present on the signal path, which reduces the chance of errors occurring when communicating over the high-speed IEEE 488 protocol. In addition, the amount of EMI suppression provided by this cable is especially beneficial in industrial settings due to the presence of electrical noise from such things as power equipment and switching devices.
In addition, the part number 763061-03 connects GPIB-based data acquisition systems, ATE systems, semiconductor test station systems, and legacy systems used to control older instrumentation commonly found in the electronics manufacturing industry and aerospace testing industry. The cable works with all GPIB controllers manufactured by National Instruments, all PCI/PCIe GPIB interface cards made by National Instruments, and all USB-to-GPIB adapters that comply with IEEE 488. Engineers using oscilloscopes, signal generators, power supplies, and network analyzers that rely upon GPIB connectivity to extend and connect their instrument chains will also find the 763061-03 an exact match to build out their GPIB instrument connections using an NI-based measurement platform.
| Model | 763061-03 |
|---|---|
| Part Number | 763061-03 |
| Manufacturer | National Instruments |
| Brand | Emerson |
| Part Type | GPIB Extension Cable (Male to Female) |
| Connector A | 24-Pin Male GPIB, Shielded |
| Connector B | 24-Pin Female GPIB, Shielded |
| Cable Length | 4 m |
| Shielding | Dual-Layer (Braid + Foil) |
| Bus Topology | Daisy-Chain, Up to 15 Instruments |
| Jacket Material | Flame-Retardant PVC |
| Operating Temperature | 0 °C to 55 °C |
