PCIe-8244

4.5/5 | 9 ratings

Modular Systems > National Instruments > Frame Grabbers

Part Number PCIe-8244
Manufacturer/Brand National Instruments
Description: PCIe-8244, 4-Port, Frame Grabber Device
Request for Availablility
Fast Quote
Quoted Price
Same Day Calibration Available
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing

Need an Official Quote?



Or speak to a sales representative for additional information:


National Instruments PCIe-8244 Frame Grabber Device

The PCIe-8244 (Part Number: 782890-01) Frame Grabber Device can give power to the camera straightforwardly through the USB 3.0 bus. As indicated by the USB 3.0 specifications, the most extreme power that can be provided is 4.5 watts at 5 volts. If there are different gadgets that require a lot of intensity, it is conceivable that there is inadequate power being provided to the camera. For this situation, the user may wish to explore the utilization of a USB 3.0 controlled center. To guarantee that the camera can send information at the appraised speed, it would be ideal if the user guarantees that the USB 3.0 host controller interface and the motherboard bolster PCIe 2.0 information throughput rates, which is adequately 384 MB/s. PCIe 1.0 engineering cannot surpass 180 MB/s, while general PCI bolsters just 133 MB/s.

Ensure that the host controller interface and/or the motherboard bolster rendition 3.0 of the USB standard as opposed to adaptation 2.0. It is conceivable that the USB 3.0 camera is running on USB 2.0, yet at only 480 Mb/s, the throughput of USB 2.0 is fundamentally not as high as USB 3.0. This is a kind of PSE that goes about as transitional and between a non-PoE (conventional) switch and PD by infusing power into the link. Midspans give a simple method for joining PoE into a current system, since the user does not have to supplant any current switches or foundation. PoE Injector is a basic PSE that infuses control into a solitary Ethernet link. The midspan commonly gives capacity to a few Ethernet ports.

ModelPCIe-8244
ManufacturerNational Instruments
Part Number782890-01
TypeFrame Grabber Device
Number of Ports4 Ports
Speed1.5 Mbps, 12 Mbps, 480 Mbps, 5 Gbps
Camera InterfaceUSB3 Vision
I/O Connectors4 × USB 3.0 connectors
PCI Express Compliance2.0
Bus PoweredYes
Power Requirements+12 V, +3.3 V - 0.32 A, 1.8 A
Dimensions5.47 in. × 2.52 in.
Weight0.21 lb.
Driver SoftwareNI-IMAQdx 4.1
NI Vision
Renesas µPD720202
Warranty2-3 Year Warranty
PCIe-8244 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for PCIe-8244:

748721-01, 782890-01

National Instruments PCIe-8244 Frequently Asked Questions



Question: What type of cameras is the PCIe-8244 best used with?



Answer: The PCIe-8244 is designed to be used with USB3 Vision cameras.



Question: What can I do to set a benchmark of the speeds my camera can reach using the NI PCIe-8244?



Answer: To test out the NI PCIe-8244 device’s speed with one camera, log into an AVI file with just one camera. This will give you a benchmark to see what speeds it can hit.



Question: What type of cable can I use with the PCIe-8244?



Answer: You should use only USB 3.0 cables that are SuperSpeed-certified with the PCIe-8244.
