National Instruments PS-15 Industrial Power Supply

The NI PS-15 (Part Number: 781093-01) comes equipped with many useful advantages, such as a long duration of life, a large power reserve, and a tiny size. This Industrial Power Supply can be used with the following National Instruments devices: CompactRIO, CompactDAQ, Single-Board RIO, touch panel computers, and Smart Cameras. The National Instruments NI PS-15 has 120 W output power, 24 to 28 V output voltage, and 5 A output current.

The NI PS-15 has four output terminals: two positive output terminals and two negative output terminals. The two negative terminals are wired together internally and the two positive terminals are wired together internally as well.

This Power Supply can be mounted in a few different ways. There are optional accessories for wall, panel, and side mounting. The user can even use the DIN-rail mounting bracket with the side mount kit for a low-profile DIN-rail installation. The DIN-rail system and spring clamp terminals for the NI PS-15 Industrial Power Supply do not necessitate tools, ensuring installation is quick and simple.

The large range and autoselect input voltages aid the user with preventing mistakes. Additionally, the extensive operating temperature range and great EMI immunity allow for hassle-free functioning, even under difficult settings. A unique feature of the NI PS-15 Power Supply is that the 20% output power reserves can be utilized in an ongoing manner for ambient temperatures less than 45 °C. Also, the AC 100-120 V/200-240 V Auto-select input ensures usage and installation worldwide are easy.

The National Instruments PS-15 Power Supply is meant for installation in an enclosure. This model is created for general use for applications, such as instrumentation equipment, communication, office, and industrial control. The NI PS-15 should not be used in aircraft, nuclear devices, trains, or other applications where a failure of the power supply could result in harming people.

The PS-15 weighs 500 g, and measures 32 x 124 x 117 mm. in physical dimensions. The power supply device has recommended operating and storage temperature ranges of –25 °C to 70 °C and –40 to 85 °C respectively, a non-condensing relative humidity range of 5 to 95%.

ModelPS-15
ManufacturerNational Instruments
Part Number781093-01
TypeIndustrial Power Supply
Output Power120 W
Temperature Range-25 to +70°C
Power Reserve20%
Dimensions32 x 124 x 117 mm.
Weight500 g
WarrantyThree Year Warranty
PS-15 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for the PS-15:

155478A-01, 195770A-01, 195770B-01, 781093-01


Associated NSNs for the PS-15:

6130-01-600-8356 (6130016008356), 6130-01-600-8356 (6130016008356)

National Instruments PS-15 Frequently Asked Questions



Question: How many output terminals does the PS-15 have?



Answer: The PS-15 has four output terminals, which deliver two positive and two negative output terminals.



Question: Can the PS-15 National Instruments be used in series to boost the output voltage?



Answer: Yes, the PS-15 National Instruments can be used in series to boost the output voltage.



Question: Which precautions should be taken when creating a redundant power system for the NI PS-15?



Answer: When creating a redundant power system for the NI PS-15, the user should link every power supply to different phases or circuits and utilize individual input fuses for every power supply.



Question: Which type of load can the PS-15 supply?



Answer: The PS-15 can supply any type of load, including unlimited capacitive and inductive loads.
