National Instruments 780688-02 Software-Selectable PXI CAN Interface Module
The National Instruments 780688-02 (PXI-8513/2) is a 2-port, software-selectable CAN interface module for PXI systems. Driven by the NI-XNET driver framework, it supports High-Speed/FD CAN (up to 1 Mbps), Low-Speed/Fault-Tolerant CAN (10 to 125 kbps), and Single-Wire CAN (33.3 to 83.3 kbps, requiring 8 to 18 VDC bus power) on a per-port basis without hardware modifications. The module features hardware-accelerated frame processing for up to 192 frames, 1 µs timestamping precision, and support for external timebase inputs. Interface connectivity is provided via standard front-panel 9-pin male D-SUB connectors for direct field wiring.
Built for seamless system synchronization, the module incorporates 500 VDC galvanic isolation (Measurement Category I) to prevent ground loops and shield host electronics from noise. Front-panel SMB connectors allow for external clock and trigger I/O synchronization, while the backplane connector provides direct access to 7 RTSI trigger lines and 1 clock line for system-wide timing alignment across PXI and PXI Express hybrid slots.
Measuring 4.2 in x 6.6 in and weighing 3.6 oz, the module draws 640 mA nominal from the PXI backplane's +5 VDC supply rail. Rated for operational temperatures from 0°C to 55°C (10% to 90% RH non-condensing) and 0.3 grms random vibration (5 to 500 Hz), it conforms to IEC 61010-1 safety, EN 61326 EMC, and CE standards—making it an ideal choice for hardware-in-the-loop (HIL) simulation, automated testing, ECU validation, and bus monitoring in industrial environments.
| Model | 780688-02 |
|---|---|
| Model Name | PXI-8513 |
| Part Type | 2-Port, Software-Selectable PXI CAN Interface Module |
| Supply Voltage | +5 VDC (from PXI backplane) |
| Dimensions (W × L) | 4.2 in × 6.6 in |
| Weight | 3.6 oz (102 g) |
| Current Consumption | 640 mA nominal |
| Max Baud Rate | 1 Mbps |
| Bus Power Required | 8 V to 18 V |
| Operating Temperature | 0 °C to 55 °C |
