PXI-8517

Modular Systems > National Instruments > Serial Interface Devices

Part Number PXI-8517
Manufacturer/Brand National Instruments
Description PXI-8517 2-Port FlexRay Interface Module

Speak to a sales representative for pricing & lead time:


National Instruments PXI-8517 Interface Module

The PXI-8517 (Part number: 780689-02) FlexRay Interface Module is intended for the improvement of FlexRay applications as part of the NI-XNET CAN platform.

The FlexRay physical layer on PXI interfaces is internally fueled. All things considered, there is no compelling reason to supply bus power. The COM pin serves as the reference ground for the bus signals. The impediments on sessions relate basically to a casing or its signals. For instance, if the user makes a Frame Output Queued session for frame A, then they can make a Signal Output Single-Point session for frame A. This mix of sessions is not permitted, even though written work information for a similar edge with two sessions would result in inconsistent sequences of data on the network.

The NI PXI-8517 includes a Frame Input Stream Mode. This mode reads all frames received from the network by utilizing a single stream. It is regularly used for analyzing and logging all frame activity in the system. The input data is returned as a variety of frames. Since all frames are returned, the user’s application must evaluate identification in each frame (such as a CAN identifier or FlexRay slot/cycle/channel) to decipher the frame payload data. The PXI 8517 also offers a Signal Input Waveform Mode. Utilizing the time when the signal frame is received, this mode resamples the signal data to a waveform with a fixed sample rate. This mode normally is utilized for synchronizing XNET data with DAQmx analog/digital input channels.

ModelPXI-8517
Part Number780689-02
ManufacturerNational Instruments
TypeFlexRay Interface
Ports2
Sync ConnectorSMB jack x 2
I/O CompatibilityTTL
Dimensions6.3 x 3.9 in.
I/O Connector9-pin male D-SUB for each port
WarrantyOne Year Warranty
PXI-8517 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-8517 Frequently Asked Questions



Question: What type of transceiver does the PXI-8517 have?



Answer: The PXI-8517 has a NXP TJA1080 x 2 transceiver.



Question: What is the maximum baud rate for the NI PXI-8517?



Answer: The NI PXI-8517 has a maximum baud rate of 10 Mbps.



Question: What are the power requirements for the NI PXI 8517?



Answer: The NI PXI 8517 has a power requirement of +5 VDC (±5%) 210 mA typical.

PXI-8517 Technical Specifications:


Manufacturer:National Instruments
Model:PXI-8517 (780689-02)
Type:FlexRay Interface Module
Repair Evaluation:$150
