PCI-6511

Modular Systems > National Instruments > DIO Series

Part Number PCI-6511
Manufacturer/Brand National Instruments
Description PCI-6511 64-Channel, Bank-Isolated Digital I/O Device

Speak to a sales representative for pricing & lead time:


National Instruments PCI-6511 Digital I/O Device

The PCI-6511 (Part Number: 778966-01) comes with watchdogs. The advanced outputs go to a protected recuperation state when a mistake condition is identified and the watchdog clock terminates. Watchdogs are essential when the gadget is associated with actuators, including pumps, valves, engines, and transfers. The advanced I/O gadget screens the product application. If the application neglects to react inside the time restraint, the gadget naturally sets the output lines to a client characterized safe state. The gadget stays in the watchdog state until the watchdog clock is incapacitated by the application and new I/O esteems are composed, the NI PCI-6511 is reset, or the PC is restarted. NI computerized I/O watchdogs give security against a wide assortment of mistake conditions: PC crash, add up to OS crash, application crash (programming application stops to react), driver crash (gadget driver stops to react), or PCI bus failure (communication stop to react).

With change identification, the user can consequently trigger their product application to play out an advanced read activity upon a computerized change of state. A computerized change of state is characterized as the rising edge (0 to 1 progress) or falling edge (1 to 0 progress) on at least one advanced lines. Utilizing NI-DAQmx programming innovation, a NI PCI-6511 advises the product application when the occasion is identified, making the application consequently play out a read task. To limit the impacts of uproarious information lines, the user can utilize programmable information channels and change recognition to take out misleading change discovery occasions caused by clamor or glitches. NI-DAQmx additionally incorporates multithreaded gushing innovation so computerized change identification occasions can happen freely of other information procurement exercises, such as simple info or output events.

ModelPCI-6511
ManufacturerNational Instruments
Part Number778966-01
TypeDigital I/O Device
Input Lines64 Source/Sink
Output Lines0
IsolationBank
Maximum Input Voltage±30 VDC
Maximum Input Current12.5 mA/line
Propagation Delay75 μs
I/O Connector100-pin keyed female SCSI
Power Requirements+5 , +3.3 VDC - 250, 300 mA
Dimensions5.94 in × 4.75 in.
Weight3.1 oz.
Driver SoftwareNI-DAQmx
WarrantyOne Year Warranty
PCI-6511 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PCI-6511 Frequently Asked Questions



Question: What is the power consumption for the NI PCI-6511?



Answer: The power consumption for the NI PCI-6511 is 250 mA, typical for +5 VDC (±5%) and 300 mA, typical for +3.3 VDC (±5%).



Question: Are any accessories required for the PCI-6511?



Answer: Yes, the PCI-6511 requires a connector block and an I/O cable.



Question: What is the programmable power-up states response time for the NI PCI 6511?



Answer: The programmable power-up states response time for the NI PCI 6511 is 400 ms.



Question: Which driver software should be used with the PCI 6511?



Answer: NI-DAQmx driver software should be used with the PCI 6511.

PCI-6511 Technical Specifications:


Manufacturer:National Instruments
Model:PCI-6511
Part Number:778966-01
Type:Digital I/O Device
Repair Evaluation:$150
