National Instruments NI-5783 Transceiver Adapter Module for FlexRIO

The National Instruments NI-5783 is a Transceiver Adapter Module designed for FlexRIO systems. This model is available in two variations: a Butterworth filter variant (784364-01) for time-domain applications and an elliptic filter variant (784364-02) for frequency-domain applications. Both versions of the NI-5783 come with DC-coupled inputs and have similar specifications. This module is only compatible with Kintex 7 based PXI FPGA modules and the standalone controller for FlexRIO. This device offers 100 MS/s analog input sampling and 400 MS/s analog output update rate.

The National Instruments NI-5783 is the ideal answer for applications in electronic warfare, software defined radio, machine control, and medical imaging. This device offers 4 simultaneously sampled, single-ended analog input channels through 4 HDBNC (high-density BNC) type connectors. Additionally, this module offers 4 simultaneously updated, single-ended outputs through HDBNC AO connectors.

To generate analog outputs, the National Instruments NI-5783 Transceiver Adapter Module comes equipped with a high-performance 16-bit, Quad type digital-to-analog converter (DAC). Unlike its predecessors, this device has a single connector for both the CLK IN and REF IN signals. This connector supports AC input coupling and has a Reference input voltage and Sample clock input range of 0.75 to 5.2 Vpk-pk and 0.4 to 5.2 Vpk-pk respectively.

The National Instruments NI-5783 module can receive TRIG signals through 1 single-ended channel. The TRIG connector supports DC coupling and has 10 kΩ rated input, along with 50 Ω rated output impedance. This Transceiver Adapter Module consumes 4.6 watts of power, while operating in typical conditions.

ModelNI-5783
ManufacturerNational Instruments
Part Numbers784364-02, 784364-01
TypeTransceiver Adapter Module for FlexRIO
Analog Input Channels4
Analog Output Channels4
Analog Input Sampling Rate100 MS/s
Dimensions5.1 x 0.8 x 4.7 in.
Weight14.8 oz.
WarrantyOne Year Warranty
NI-5783 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments NI-5783 Frequently Asked Questions



Question: Why are there two NI-5783 part numbers?



Answer: The NI-5783 has two filter types available: part number 784364-01 with an elliptic filter and part number 784364-02 with a Butterworth filter.



Question: What type of analog input connector does the NI 5783 have?



Answer: The NI 5783 has an HDBNC (high-density) BNC analog input connector.



Question: What is the total power value for the NI-5783?



Answer: During typical operation, the total power for the NI-5783 is 4.6 W.



Question: Which FPGA is compatible with the NI 5783?



Answer: The NI 5783 is compatible with the Kintex-7 FPGA.
