National Instruments PXIe-2738 PXI Matrix Switch Module

The National Instruments PXIe-2738 (Part Number: 782835-38) is an 8 x 32, 2-wire high-density Matrix Switch Module that routes signals with bandwidths up to 10 MHz within automated test systems, using electromechanical relays to perform immediate switch operations. The NI PXIe-2738 is designed for applications and functions that enable the monitoring of deployed systems.  This Matrix Switch Module features onboard relay count tracking, a temperature sensor, functional and resistive relay self-tests, and a range of advanced features that provide a smarter way to tackle applications used in defense, aerospace, and electronics industries.

The PXIe-273x Matrix Switch Modules are designed to provide maximum versatility for switching systems by allowing a channel-to-channel connection, using electromechanical armature relays, field-effect transistor (FET) relays, reed relays, and solid-state relays, offering users the ability to choose a matrix that ideally suits their specific requirements.

This module has a maximum switching voltage of 100 V (channel-to-channel) and 100 V, CAT O (channel-to-ground). It is designed to carry signal voltages less than 70 Vrms, 100 Vpk, or 100 VDC, and can withstand up to 500 V impulse voltage.

The driver software for this module is the IVI-compliant NI-SWITCH software, which allows the user to program the module. Ni-SWITCH comes with example programs and helpful documents. The PXIe-2738 PXI Matrix Switch Module’s dimensions (L x W x H) are 21.6 cm x 2.0 cm x 13.0 cm (8.5 in. x 0.8 in. x 5.1 in.) and the weight is 423 g (14.9 oz).

ModelPXIe-2738
Part Number782835-38
ManufacturerNational Instruments
TypePXI Matrix Switch Module
Crosspoints256
Relay TypeElectromechanical, non-latching
Maximum Switching Power60 W, 62.5 VA
Dimensions8.5 x 0.8 x 5.1 in.
Weight14.9 oz.
WarrantyOne Year Warranty
PXIe-2738 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXIe-2738 Frequently Asked Questions



Question: What is the minimum switching load for the PXIe-2738?



Answer: The minimum switching load for the PXIe-2738 is 20 mV/1 mA.



Question: What is the topology of the NI PXIe-2738?



Answer: The topology of the NI PXIe-2738 is a 2-wire 8 x 32 matrix.



Question: What is the simultaneous drive limit for the PXIe-2738?



Answer:  The simultaneous drive limit for the PXIe-2738 is 90 relays.



Question: What type of front panel connector is on the NI PXIe-2738?



Answer: The NI PXIe-2738 has a 160 DIN 41612, 160 positions, male front panel connector.
