SCXI-1300 National Instruments Terminal Block | Apex Waves | Image SCXI-1300 National Instruments Terminal Block | Apex Waves | ImageSCXI-1300
SCXI-1300 National Instruments Terminal Block | Apex Waves | Image
SCXI-1300 National Instruments Terminal Block | Apex Waves | Image
SCXI-1300 New

SCXI-1300

4.8/5 | 6 ratings

Modular Systems > National Instruments > SCXI

Part Number SCXI-1300
Manufacturer/Brand National Instruments
Description: SCXI-1300, General-Purpose, Screw Terminal, Terminal Block
In Stock | Ships Today
Fast Quote
Quoted Price
Lowest Price Guarantee
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing
2 year warrantyRefurbished
*What is Refurbished?
Quoted Price
Fully tested
2yr warranty
  Get Pricing

Need an Official Quote?


*Most customers receive their price in about 15 minutes.

Or speak to a sales representative for pricing & lead time:


National Instruments SCXI-1300 Terminal Block

Featured with an onboard temperature sensor, the National Instruments SCXI-1300 (Part Number: 777687-00) is a General-Purpose Terminal Block. With this model, the user can link input signals to the SCXI-1102 Series, SCXI-1104, and SCXI-1100 modules. Apart from this, the SCXI-1300 can also be used with the SCXI-1181K and SCXI-1300 modules. This module is designed in such a way that it can easily be mounted to the front of SCXI modules. The NI SCXI-1300 comes equipped with a 96-pin DIN output connector through which it is connected to the SCXI module. The integrated cold-junction sensor on the SCXI-1300 can operate with 1.3 °C accuracy from 0 to 50 °C and repeatability of ± 0.5 °C. The sensor generates an output of 10 mV/°C (to 0.5 V from 0 to 50 °C).

Using a 32-channel SCXI module with the SCXI-1300 Terminal Block allows the user to interconnect signals via screw terminals. To connect to an SCXI module`s 32 differential inputs, this model features 32 pairs of screw terminals. It also has two screw terminals that are utilized to connect to the functional chassis ground pins of the module. In addition, the NI SCXI-1300 comes with a solder lug as a chassis ground for safety purposes. Additional screw terminals are available to connect to the SCXIbus GUARD, the SCXI module OUTPUT, and the SCXI module AOREF. The National Instruments SCXI-1300 is a small device, only 49.3 by 4.3 by 18.8 cm and it is designed to operate within a broad temperature range.

ModelSCXI-1300 (777687-00)
ManufacturerNational Instruments
SeriesSCXI
TypeTerminal Block
Compatible ModulesSCXI-1100, SCXI-1102 Series, SCXI-1104, SCXI-1181, and SCXI-1181K modules
Sensor Output±10 mV/˚C
Maximum Field Wire Gauge26-16 AWG
WarrantyOne Year Warranty
SCXI-1300 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments SCXI-1300 Frequently Asked Questions



Question: Which type of application is the SCXI-1300 recommended for?



Answer: The SCXI-1300 is ideal for general-purpose voltage applications.



Question: Where does the SCXI-1300 mount on the SCXI module?



Answer: The SCXI-1300 mounts to the front of the SCXI module.



Question: What is the maximum field wire gauge on the NI SCXI-1300?



Answer: 26-16 AWG is the maximum field wire gauge on the NI SCXI-1300.



Question: What is the sensor output for the SCXI-1300?



Answer: The sensor output for the SCXI-1300 is ±10 mV/˚C.
