SCXI-1331 In Stock | Ships Today
SCXI-1331, 64-Channel, Terminal Block
Need an Official Quote?
National Instruments SCXI-1331 Terminal Block
The SCXI 1331 (Part Number: 777687-31) Terminal Block mounts to the front of an SCXI-1127 or SCXI-1128 Multiplexer/Matrix Switch Module, providing 64 screw terminals for connections. The SCXI-1331 is the best choice when utilizing the SCXI-1127 or SCXI-1128 to scan thermocouple of voltage signals or when the user requires a matrix configuration besides 8 columns x 4 rows. The SCXI 1331 can configure the SCXI-1127/1128 Switch Module as a 64 x 1, 1-wire matrix, a 32 x 1, 2-wire matrix, or a 16 x 1, 4-wire matrix. This General-Purpose Terminal Block is designed for signal conditioning and cold-junction compensation. The NI SCXI-1331 is suggested for multiplexer or customized matrix applications. It has a maximum voltage of 300 V (CAT II) and a maximum current of 2 ADC, 2 AAC (per channel).
The 64 screw terminals on the NI SCXI-1331 Terminal Block enable the user to access the matrices. The Terminal Block additionally has terminals for external trigger signals. When the user is ready to connect signals to the SCXI-1331, they must first prepare the signal wire by stripping the insulation (no more than 7 mm from the end of the wire). Then, take the top cover screw off and take off the top cover. The user can then loosen the two strain-relief screws on the strain-relief bar and run the signal wires through the strain-relief opening. Next, put the stripped end of the wire completely into the terminal and secure the wire by tightening the screw of the terminal. The user can then link the safety earth ground to the safety ground lug and tighten the two screws on the strain-relief assembly to make sure the cables are secure. Lastly, reinstall the top cover and put the top cover screw back.
The NI device has a recommended operating temperature range of 0 °C to 50 °C, a storage temperature range of –20 °C to 70 °C, and a non-condensing relative humidity range of 10% to 90%. It is designed to comply with the following safety standards for electrical equipment: - IEC 61010-1, EN 61010-1, - UL 61010-1, and - CAN/CSA-C22.2 No. 61010-1.
| Model | SCXI-1331 |
|---|---|
| Part Number | 777687-31 |
| Manufacturer | National Instruments |
| Type | Terminal Block |
| Screw Terminals | 64 |
| For Use With: | SCXI-1127 or SCXI-1128 Multiplexer/Matrix Switch Modules |
| Maximum Voltage | 300 V, CAT II |
| Maximum Current | 2 ADC, 2 AAC (per channel) |
| Warranty | Three Year Warranty |
| SCXI-1331 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the SCXI-1331:
184268B-01, 184268C-01, 184268D-01L, 777687-31
National Instruments SCXI-1331 Frequently Asked Questions
Question: Are you able to handle the exposed pins on the connectors of the SCXI-1331?
Answer: Never touch the exposed pins of the connectors on the SCXI-1331 without grounding yourself with a grounding strap or by touching a grounded object.
Question: What is the safest way to remove the SCXI 1331 from the package?
Answer: To remove the SCXI 1331 from the package, be sure to touch the antistatic package to a metal part of your computer chassis before you remove it. Then, check for loose parts or signs of damage.
Question: What are the matrices that are available when you connect the NI SCXI-1331 terminal block to the SCXI-1127/1128 switch module?
Answer: The matrices available when you connect the NI SCXI-1331 terminal block to the SCXI-1127/1128 switch module are a 64 × 1, 1-wire matrix, a 32 × 1, 2-wire matrix, or a 16 × 1, 4-wire matrix.
SCXI-1331 PDF Manuals
NI SCXI 1127 SPECIFICATIONS.PDF
NI SCXI 1128 SPECIFICATIONS.PDF
NI SCXI-1331 INSTALLATION INSTRUCTIONS.PDF
SCXI 1127 1128 USER MANUAL.PDF
