National Instruments SHC68-68-RDIO Cable
The National Instruments SHC68-68-RDIO (Part Numbers: 191667-01 and 191667-0R5) is a high-performance Shielded Cable. This product is specifically designed for R Series devices. You can use this cable with the digital input/output (I/O) connectors on the PXI/PCIe/PCI-781xR, 784xR, 785xR, and 783xR R Series devices. The SHC68-68-RDIO should not be utilized with the PXIe-785xR, PXIe-782xR, PXIe-784xR, or the USB R Series devices. The NI SHC68-68-RDIO features a combination of a 68-pin D-type female and a 68-pin VHDCI male connector. This shielded cable is available in 0.5 m or 1 m lengths and can be connected to 68-pin terminal blocks.
The National Instruments SHC68-68-RDIO Shielded Cable has external shielding, as well as twisted I/O lines– a combination of the technique utilized to ensure maximum noise immunity and signal integrity. You can also use the NI SHC-68-68-RDIO Cable with the NI cRIO-9151 Chassis to achieve expansion or signal conditioning for digital and analog I/O.
| Model | SHC68-68-RDIO |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 191667-01 and 191667-0R5 |
| Type | Cable |
| Connectors | VHDCI 68-pin male connector and 68-pin female 0.050 D-type connector |
| Cable Lengths | 0.5 m or 1 m |
| Shielded | Yes |
| Warranty | 2-3 Year Warranty |
| SHC68-68-RDIO Manual | User Manual and Maintenance Manual Available for Download |
Associated part numbers for the SHC68-68-RDIO:
189589-01, 191667-01, 191667-0R5
Associated NSNs for the SHC68-68-RDIO:
6150-01-626-7777 (6150016267777)
National Instruments SHC68-68-RDIO Frequently Asked Questions
Question: Is the SHC68-68-RDIO Cable low leakage?
Answer: No, the SHC68-68-RDIO is not low leakage.
Question: What are the back and front end connectors of the SHC68-68-RDIO?
Answer: The front end connection is a 68-pin Female SCSI type, while the back end connection is 68-pin Male VHDCI
Question: Is the SHC68-68-RDIO shielded?
Answer: Yes, the cable is shielded.
SHC68-68-RDIO PDF Manuals
ARCHIVED DRIVVEN DIFFERENTIAL DIGITAL I O MODULE USER MANUAL.PDF
ARCHIVED DRIVVEN ENGINE SYNCHRONOUS TTL OUTPUT MODULE KIT USER MANUAL.PDF
ARCHIVED DRIVVEN NOX SENSOR KIT FOR COMPACTRIO USER MANUAL.PDF
ARCHIVED DRIVVEN O2 SENSOR MODULE KIT USER MANUAL.PDF
ARCHIVED DRIVVEN PORT FUEL INJECTOR DRIVER MODULE KIT USER MANUAL.PDF
ARCHIVED DRIVVEN THROTTLE DRIVER MODULE KIT USER MANUAL.PDF
COMBUSTION ANALYSIS SYSTEM SOFTWARE USER MANUAL.PDF
DRIVVEN AD COMBO MODULE KIT USER MANUAL AND SPECIFICATIONS.PDF
DRIVVEN DIRECT INJECTOR DRIVER MODULE KIT USER MANUAL AND SPECIFICATIONS REV F .PDF
GETTING STARTED WITH R SERIES MULTIFUNCTION RIO.PDF
NI 9151 COMPACTRIO R SERIES EXPANSION SYSTEM USER MANUAL AND SPECIFICATIONS.PDF
NI 9751 DIRECT INJECTOR DRIVER MODULE USER MANUAL.PDF
NI 9752 USER MANUAL AND SPECIFICATIONS.PDF
NI 9753 USER MANUAL AND SPECIFICATIONS.PDF
NI 9754 USER MANUAL AND SPECIFICATIONS.PDF
NI 9757 USER MANUAL AND SPECIFICATIONS.PDF
