Next-Gen Radars: Seeing Further and Clearer

Insights Into Modern Radar and Communication Systems From Proakis and Salehi’s Communication Systems Engineering (2002).

Radar, Communications Systems

In the military, aerospace, and defense industries, being able to “see” the environment clearly and from a distance is not only advantageous, but also imperative. Systems for communication and radar, which are vital tools for monitoring, navigating, and resolving disputes, evolve with the times. However, the effectiveness of these complex systems is often correlated with the capabilities and limitations of the testing apparatus used throughout development, maintenance, and improvement.

This article explores the complexities of the effects of legacy test equipment on communication and radar systems, looking at both the problems and the areas that could be improved, as gathered by insights from Communication Systems Engineering by Proakis and Salehi. We’ll examine how next-generation radars are overcoming these obstacles to provide clearer, more accurate, and more comprehensive detection capabilities. These obstacles range from the sampling limits imposed by bandlimited processes to the lingering effects of Gaussian noise in earlier systems.

In addition, we will investigate the fundamental role of bandpass processes, the behavior of Gaussian and white noise, and random processes in the frequency domain. These theoretical insights are more than just theoretical; they form the basis for future advancements in radar technology, which will enable forces to operate in more complex scenarios with greater security and productivity.

Understanding Random Processes in the Frequency Domain

Random processes in the frequency domain refer to the analysis and characterization of random signals based on their frequency content. This approach is important in understanding how these signals behave over time, specifically in systems where the signal’s spectral composition impacts performance.

When discussing random processes, one fundamental idea is the power spectral density (PSD), which depicts how a random signal’s power is dispersed across various frequencies. Because it sheds light on the system’s intrinsic noise characteristics and bandwidth needs, the PSD is especially useful. One popular model in communication theory, white noise, for instance, has a consistent PSD across all frequencies, indicating an equal power distribution and its role as a noise generator across different frequency bands. Engineering professionals can create filters, forecast system behavior, enhance performance, and lessen undesired effects like noise and interference by analyzing random processes in the frequency domain.

The properties of random processes in the frequency domain have a significant impact on radar and communication system performance. According to our text, “The power spectrum of a stochastic process provides a comprehensive view of its frequency domain characteristics which are essential for analyzing transmission over LTI systems.” (Proakis & Salehi, 2002, p. 177)

By adjusting the spectrum characteristics of the signals to improve clarity and reach, engineers may optimize radar systems thanks to this basic understanding. Developers can build systems that offset potential losses by anticipating how signals may deteriorate over distance and across different media by knowing the power spectrum.

The Impact of Gaussian and White Processes

When examining the several kinds of noise that impact radar systems, Gaussian and white noise processes come into play. Gaussian processes are pivotal in modeling the effects of noise in radar systems due to their inherent characteristics that simplify analysis through Gaussian noise assumptions. These presumptions are important because Gaussian noise may be efficiently filtered and studied due to its well-defined statistical features, which enables more precise signal interpretation.

Similarly, “White processes, being mathematically described as having constant power spectral density across all frequencies, serve as a fundamental model for representing thermal noise in communication systems.” (Proakis & Salehi, 2002, p. 191) White noise has a big impact on system design because of its even power distribution; it affects everything from signal processing techniques to the resilience of the system against outside noise.

Bandlimited Processes and Sampling

Another important factor that significantly affects radar systems’ effectiveness is the limitations imposed by bandlimited processes. As Communication Systems Engineering states, “Bandlimited processes are crucial in radar applications because they define the limits on how signals can be sampled without loss of information, adhering to the Nyquist rate.” (Proakis & Salehi, 2002, p. 192) Following this protocol guarantees that digital radar systems can accurately and high-resolution target detection by converting analog radar returns into digital signals without sacrificing any important information.

Sampling theories are essential to the design of the hardware and software that make up the core of contemporary radar systems because they specify the frequency at which radar signals must be sampled and processed in order to preserve integrity.

The Role of Bandpass Processes in Increasing Radar Performance

Bandpass techniques are essential for improving the performance of communication and radar systems. As Communication Systems Engineering clarifies, “Bandpass processes are used to model the behavior of radar signals that are confined to a specific band of frequencies.”  (Proakis & Salehi, 2002, p. 195) This confinement is essential since it improves the signal-to-noise ratio by removing undesirable frequencies that don’t add to signal intelligence.

In radar systems, bandpass filtering is crucial for separating the frequencies that provide the most valuable data about targets or surrounding characteristics. Systems can improve detection and identification accuracy by gaining a better grasp of the scanned environment, concentrating on these important frequencies.

Shannon-Nyquist Theorem and Range in Modern Radar Systems

The exploration of random processes, Gaussian and white noise, bandlimited processes, and bandpass filtering reveals the complex interplay of factors that influence radar and communication systems. These concepts, grounded in the foundational theories provided by Communication Systems Engineering, are crucial for pushing the boundaries of what modern radar systems can achieve. A key principle of signal processing, the Shannon-Nyquist Sampling Theorem, remains a basic premise that directs this integration.

The theorem, elegantly captured by the equation:

​illuminates a path for engineers and scientists in the field. Here, s(t) represents the continuous-time signal being sampled, and W denotes the bandwidth. According to this theorem, if a signal is sampled at least twice its highest frequency—referred to as the Nyquist rate—it can be completely reconstructed from its samples.

This principle has major implications for radar systems. Next-generation radars can attain better detection capabilities and higher resolution even in congested situations by following this sampling principle. This is particularly important when updating legacy systems, as it may frequently be difficult to strike a balance between the old and the new. By making sure that more recent, high-frequency radar signals are precisely recorded and processed without losing important data, putting this theory into practice enables a more seamless transition.

In addition, the theorem’s application extends beyond just signal acquisition—it plays a pivotal role in system testing and calibration. Legacy test equipment, when calibrated to sample at appropriate rates as dictated by the Nyquist theorem, ensures that the systems are not only compatible with modern standards but also prepared to handle the broader spectrum of signals used in contemporary radar and communication technologies.

Looking to upgrade or clear out your test equipment inventory? Don’t let outdated or unused equipment gather dust—turn it into an opportunity. Contact us today to find out how we can meet your equipment needs and help you maximize your resources.

Explore Our Inventory | Sell Your Surplus

Conclusion: Looking Into the Future of Radar Technology

The next generation of radar systems will surely be able to “see” farther and clearer, as well as more accurately and in complex environments thanks to the integration of these principles with new developments in signal processing, materials science, and artificial intelligence. This will undoubtedly happen as technology advances. The ongoing development and application of these theories will open doors for innovations that have the potential to completely reimagine aerospace and defense’s strategic capabilities by overcoming historical constraints with the help of science and creative engineering.


Proakis, J. G., & Salehi, M. (2002). Communication Systems Engineering (2nd ed.). Upper Saddle River, NJ: Prentice Hall.
